Product name:
Small steam generator
Model: LDR(3-18)-0.4Z
Heating power: 3KW----18KW
Voltage: 220V/380V
Rated operating pressure: 0.4~0.7Mpa
Vapor capacity: 3.8~22.8kg/h
Effective water volume: 28L
Power: 380V 50Hz
Heating Power: 20kW --144 kW two standards
Steam Feeding: 30Kg_200Kg/H
Water Supply: According to the standard of water using in the boiler
Designing Pressure: 0.70MPa
Designing Temperature: 170 celsius degree
|
Model |
Steam Output Kg/h |
Rated Power KW |
Rated Operating Current A |
Electric Cable Paramete |
Outline Dimension mm |
Weight Kg |
Steam outlet Valve Dia.
DN |
Blown Down Valve Dia.
DN |
Water Inlet Valve Dia.
DN |
|
LDR0.27-0.7 |
270 |
192 |
290 |
3*120+2(Copper Cable) |
1000*1000*1800 |
520 |
40 |
40 |
25 |
|
LDR0.30-0.7 |
300 |
216 |
328 |
3*150+2(Copper Cable) |
1000*1000*1800 |
520 |
40 |
40 |
25 |
|
LDR0.34-0.7 |
340 |
240 |
364 |
3*185+2(Copper Cable) |
1000*1000*1800 |
520 |
40 |
40 |
25 |
|
LDR0.4-0.7 |
400 |
288 |
436 |
3*240+2(Copper Cable) |
1000*1000*1800 |
520 |
40 |
40 |
25 |
|
LDR0.5-0.7 |
500 |
360 |
545 |
Double 3*120+2(Copper Cable) |
1200*1200*2000 |
680 |
40 |
40 |
25 |
|
LDR0.6-0.7 |
600 |
432 |
655 |
Double 3*120+2(Copper Cable) |
1200*1200*2000 |
680 |
40 |
40 |
25 |
Beijing Double Dragon International Industrial & Mining Machinery Co., Ltd. is a company authorized by the Chinese Foreign Economy and Trade Committee which also get the right to do import and export business independently. The company locates at Beijing, the capital of China, and seats at No. 2-1803 Soubao Business Center, No. 16 Nansanhuan Xilu, Beijing, China.
Bidragon International as a professional export & import company, is one of the selling leaders of agricultural machineries in China, for we have the long stable cooperation with many manufactures of agricultures machineries & grain processing machineries. And most of our partnerships are among the best enterprises in China machinery industry. Many of them are modern enterprises with long histories of manufacturing agricultural machinery. with top quality products, perfect service, a visionary management, Beijing Double Dragon International Agricultural Machinery Co., Ltd. is ready to meet any of the customer's requests from overseas.
As a professional export and import company, our company is the sole agent in overseas market for several manufacturers, such as Changge Chili Processing Machinery Factory, Hangzhou Biomass Boiler Co., Ltd. And Hebi Yuxing Mine Hoist Factory, and they are professional manufacturers in their fields by super quality and the best service.
Our company is engaged in four ranges of machinery:
1. Spice processing machinery, such as chili dryer, chili stem cutter, chili dry washer, chili grinder, coriander and turmeric grinder, etc...
2. Different kinds of boilers, such as wood pellet boiler, straw pellet boiler, rice husk fired boiler, wood dust fired boiler, wood fired boiler and ion exchange resin for boilers.
3. Mine equipments, such as mine hoists, mine winder, mine windlass, mine winch, infrared methane sensor and other kinds of safety detecting devices for coal mines and other mines.
4. Small enrichment machinery, such as tooth picker making line, nail making machine by waste steel wire, skewer(barbecue stick) making line, etc...
