ZHEJIANG HUICHUANG INDUSTRY&TRADE Co., Ltd is the key enterprise in Pan'an City with the new plant area 20000 square meter. We are the professional manufacuturer in series of Garden Tools and Power Tools such as gasoline engine, gasoline generator, gasoline chainsaw, brush cutter, hedge trimmer, long pole tools, tillers, power tools, welders, rotary hammers, etc.
And the Specification of Single cylinder Air-cooled 4-stroke OHV 3kVA home use gas generator as following:
Model |
HC3500S |
Type |
Revolving field type 2 poles generator |
Voltage Regulate |
Capacitance & AVR |
AC Frequency (Hz) |
60 |
50 |
AC Output Voltage (V) |
110;120;110/220;120/240 |
220;230;115/230 |
Cont. AC Output (VA) |
2800 |
2500 |
Max. AC Output (VA) |
3200 |
2800 |
DC Output (V/A) |
12 / 8.3 |
Engine Model |
HC168F-1 |
Type |
Single cylinder,Air-cooled,4-stroke OHV |
Starting System |
Recoil |
Fuel Tank Capacity (L/gal) |
15 / 3.96 |
Packing Dimensions (mm/in.) |
605x435x450 /23.8x17.1x17.7 |
Net Weight (kg/lb) |
50 / 110.3 |
