We are the professional manufacuturer in series of Garden Tools and Power Tools such as gasoline engine, gasoline chainsaw, brush cutter, hedge trimmer, long pole tools, tillers, power tools, welders, rotary hammers, etc. HUICHUANG has its own plastic injection workshop, motor making workshop, crank workingshop and iron workshop, With the powerful technical force and strict quality-contral system pushing, our products won the reputation form the clients of Europe, America, southeast Asia and Middle East.
| ITEMMODEL | LPG2000 | LPG3000 | LPG4000 | LPG5000 | NG2000 | NG3000 | NG4000 | NG5000 |
| GENERATOR | 1.62.0kw | 2.32.8kw | 3.54.0kw | 4.05.0kw | 1.62.0kw | 2.32.8kw | 3.54.0kw | 4.05.0kw |
| Frequency(Hz) | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 |
| Rated Voltage(v) | 110V/220V,115V230V,120V/240V,220V,230V,240V |
| Cont.Output(kw) | 1.8 | 2 | 2.2 | 2.5 | 3.7 | 4 | 4.5 | 5 | 1.6 | 1.8 | 2 | 2.2 | 3.5 | 3.7 | 4 | 4.5 |
| Max.Output(kw) | 2 | 2.2 | 2.5 | 2.8 | 4 | 4.3 | 5 | 5.5 | 1.8 | 2 | 2.3 | 2.5 | 3.8 | 4 | 4.5 | 5 |
| DC output(V/A) | 12/8.3A |
| Power Factor(cos) | 1 |
| Engine Model | HC168FB | HC168FB | HC182F | HC188F | HC168FB | HC168FB | HC182F | HC188F |
| Type | OHV 25,tilt single cylinder,Forced air cooling,4-stroke |
| Displacement(cc) | 196 | 196 | 337 | 389 | 196 | 196 | 337 | 389 |
| Ignition System | TCI |
| Starting System | Recoil or Electric Starting |
| Max.Power Output(hp) | 6.5 | 6.5 | 11 | 13 | 6.5 | 6.5 | 11 | 13 |
| Oil Capacilty(L) | 0.5 | 0.6 | 1.1 | 1.1 | 0.5 | 0.6 | 1.1 | 1.1 |
| Filter | Semi-dry,Oil-bath,Foam |
| Noise level lwA Db(A) | 65(at 7m) | 67(at 7m) | 72(at 7m) | 74(at 7m) | 65(at 7m) | 67(at 7m) | 72(at 7m) | 74(at7m) |
| DIM(L*M*H)(mm) | 640×465×475 | 640×465×475 | 720×540×580 | 710×530×590 | 640×465×475 | 640×465×475 | 720×540×580 | 710×530×590 |
| Net Weight(kg) | 47 | 49 | 83 | 85 | 47 | 49 | 83 | 85 |
