Type: Revolving Magnetic Field, Self-excitation, 2 Poles, Brushless, Single/Three-phase
Voltage Regulator: Auto Regulating System
Frequency: 50Hz/60Hz
Rated AC Voltage: 110, 115, 120, 220, 230, 240, 110/220, 115/230, 120/240V (Single-phase)
380, 400, 415, 220/380, 230/400, 240/415V (Three-phase)
Max. AC Output: 3.3 kW(50Hz), 3.6 kW(60Hz)
Rated AC Output: DV3600S: 3.0 kW (50Hz), 3.3 kW (60Hz)
Power Factor: 1.0 (Single Phases), 0.8 (Three Phase)
Engine Model: DV178
Engine Type: Single-cylinder, Vertical 4-stroke, Direct-injection, Air-cooled Diesel Engine,
Displacement: 296cc
Max. Output: 6.0hp/3600rpm
Fuel: Diesel Light Fuel
Fuel Tank Capacity: 16.0L
Continuous Operating Hours: 15h(50Hz), 14h(60Hz)
Lube Oil: SAE 10-30W
Oil Capacity: 1.1L
Ignition System: Direct Injection
Starting System: Electric Started
Operating Noise Level(7m): 70-72dB(A)
Oil Alert: Yes
Fuel Gauge: Yes
Voltmeter: Yes
Pilot Light: Yes
AC Circuit Breaker: Yes
AC Socket: Yes
Electric Starter: Yes
Battery Tray Kit: Yes
DC Output: Yes (12V/8.3A)
DC Circuit Breaker: DC Fuse
4-wheel Dolly Kit: Yes
Voltage Switch: Yes (Only for Dual Voltage)
Product Dimension: 855x555x720mm
Carton Dimension: 875x575x790mm
Net Weight: 130kg
Gross Weight: 135kg
Container: 76units/20FT, 156unit/40FT
Optional Features:
1. 3-phase is available.
2. ATS: Auto Transfer Switch
