Type: Revolving Magnetic Field, Self-excited, 2 Poles, Single/Three-phase
Voltage Regulator: Auto Regulating System
Frequency: 50Hz/60Hz
Max. AC Output: 5.5KW(50Hz), 6.0KW(60Hz)
Rated AC Voltage: 110, 115, 120, 220, 230, 240, 110/220, 115/230, 120/240V (Single-phase)
380, 400, 415, 220/380, 230/400, 240/415V (Three-phase)
Rated AC Output: 5.0KW(50Hz), 5. 5KW(60Hz)
Engine Model: DV186A
Engine Type: Air-cooled, Single-cylinder, 4-stroke, Direct-injection Diesel.
Displacement: 418cc.
Max. Output: 10 HP/3600rpm
Fuel: Light Diesel
Fuel Tank Capacity: 12.5L
Continuous Operating Hours: 7h/50Hz, 6h/60Hz
Lube Oil: SAE 10-30W
Oil capacity: 1.65L
Starting System: Recoil or Recoil/Electric
Operating Noise Level(7m): 78-80dB(A)
Oil Alert: Yes (when Electric Start)
Fuel Gauge: Yes
Voltmeter: Yes
Pilot Light: Yes
AC Circuit Breaker: Yes
AC Socket: Yes
Electric Starter: Optional
Battery Tray Kit: Optional
DC Output: Yes 12V/8.3A
DC Circuit Breaker: DC Fuse
4-wheel Dolly Kit: Optional
Voltage Switch: Yes (Only for Dual Voltage Type)
Product Dimension: 740x475x590mm
Carton Dimension: 755x490x605mm
Net Weight: 90kg (E: 95)
Gross Weight: 92kg (E: 97)
Container: 99units/20FT, 207units/40FT, 276units/40HQ
NOTE: Item such as Electric started, Battery, 4-wheel kit and 3-phase are Optional
