Siemens brushless high voltage alternators (4505-3 640kw 1500rpm)
The generator comprise the main machine(revolving-field machine with cylindrical rotor and damper windings), exciter(revolving armature machine) and excitation equipment. The excitation system mainly adopts currently the world's most advanced DECS100 or UNITROL 1000 digital automatic voltage regulator which is produced by BASLER company or SWITZERLAND ABB company, by using the permanent-magnet auxiliary (ancillary)exciter system, the main-generator, the permanent-magnet auxiliary exciter and the DECS100 digital automatic voltage regulator perfectly matched the constitutes the high-quality and excellent-performance generator, which can form the generating set with internal combustion engine, steam turbine engine, steam turbine, water turbine and motor drive, and also can be the major facility or the standby equipment for ship power station, mobile power station, stationary electric power plant, emergency standby power station, small-sized hydropower station, and other power system.
If you want to know more information about thissiemens brushless high voltage alternators (4505-3 640kw 1500rpm), the high voltage can be reached to 3150v; 6300v; 10500v, please contact with us freely.
|
3150V/50HZ 1500RPM |
6300V/50HZ 1500RPM |
10500V/50HZ 1500RPM |
|
Type |
Power KW |
Current
A |
Efficiency
% |
Type |
Power KW |
Current
A |
Efficiency
% |
Type |
Power KW |
Current
A |
Efficiency
% |
|
4501-4 |
500 |
115.0 |
93.2 |
4501-4 |
500 |
57.3 |
93.2 |
4501-4 |
500 |
27.5 |
91.8 |
|
4502-4 |
560 |
128.5 |
93.4 |
4502-4 |
560 |
64.2 |
93.3 |
4502-4 |
450 |
31.0 |
91.6 |
|
4503-4 |
640 |
146.6 |
93.7 |
4503-4 |
640 |
73.3 |
93.4 |
4503-4 |
500 |
34.5 |
92.3 |
|
4504-4 |
720 |
165 |
93.8 |
4503-4 |
720 |
82.5 |
93.7 |
4504-4 |
560 |
38.5 |
91.8 |
|
|
|
|
|
|
|
|
|
|
|
|
|
