Features and Benefits
Adopt advanced DDS technology; 14 bits vertical accuracy; 512 kpts waveform length; 300 MSa/s maximum sampling rate; 120 MHz maximum output frequency
3.8 inches STN colorful LCD
Optional 16+2 channels logic signal output module DG-POD-A; Enable to reappear more Mixed signals by working with the analog channels
DG-POD-A supports RS-232, SPI, IIC and PO protocol as well as user-designed protocol based on PO
Output 10 standard waveforms, DC and user-designed arbitrary waveforms; Store up to 1024 kpts waveforms
Abundant modulation functions: AM, FM, PM, PWM, FSK; Linear/logarithm sweep and burst
Abundant output and input: Waveform output; Synchronous signal output; External modulation source, external 10MHz reference clock input, external trigger input and internal 10MHz clock output
Standard interface: USB Device, USB Host, LAN, RS-232 and GPIB; Support U-disc storage and Web remote control
Seamlessly interconnect with DS1000 series digital oscilloscope
Powerful arbitrary waveform editing software "UltraWave"
Support remote control via a command line
Clear graphical interface
Support Chinese and English menu
Button-help makes information getting easier
File management (support for U disc and local storage
|
Model |
DG3121A |
DG3101A |
DG3061A |
|
The maximum output frequency |
20 MHz |
100 MHz |
60 MHz |
|
Waveform Type |
Sine, square, sawtooth, pulse wave, white noise, DC, the index rose, fell, Sinc wave, electrocardiogram wave |
|
Sine wave |
1uHz to 120MHz |
1uHz to 100MHz |
1uHz to 60MHz |
|
Square |
1uHz to 120MHz |
1uHz to 100MHz |
1uHz to 60MHz |
|
Sawtooth |
500uHz to 36MHz |
500uHz to 36MHz |
500uHz to 30MHz |
|
Pulse |
1uHz to 1MHz |
1uHz to 1MHz |
1uHz to 1MHz |
|
White noise |
50MHz(-3d B) |
40MHz(-3d B) |
30MHz(-3d B) |
|
Output mode output |
channels |
1 |
|
Burst |
count (1to1, 000, 000 cycles) infinite, gated |
|
Sweep |
linear, exponential |
|
Amplitude characteristics |
10 mVpp ~ 10 Vpp50 Ω |
|
20 mV ~ 20 Vppinto open circuit |
|
Modulation characteristics |
modulation |
AMFMPMFSKPWM- |
|
Modulation wave frequency |
2mHz to 20kHz(FSK2mHz to 100kHz) |
|
Porter arbitrary nature |
frequency range |
1uHz to 25MHz |
|
Waveform Length |
2 pts 1 Mpts |
|
Amplitude resolution |
14 bits |
|
Sampling rate |
300MSa/s |
|
Other parameters |
Standard Interface |
USB Host & Device, RS-232, GPIB(IEEE-488), LAN |
|
Power |
100-127V/45-440Hz, 100-240V/45-60Hz, 65W |
|
Product Type |
Desktop Function / Arbitrary Waveform Generator |
|
Dimensions |
W× H× D231mm× 108mm× 365mm |
|
Weight |
3.5 kg |
