Features and Benefits
Adopt advanced DDS technology; 14 bits vertical accuracy; 512 kpts waveform length; 300 MSa/s maximum sampling rate; 120 MHz maximum output frequency
3.8 inches STN colorful LCD
Optional 16+2 channels logic signal output module DG-POD-A; Enable to reappear more Mixed signals by working with the analog channels
DG-POD-A supports RS-232, SPI, IIC and PO protocol as well as user-designed protocol based on PO
Output 10 standard waveforms, DC and user-designed arbitrary waveforms; Store up to 1024 kpts waveforms
Abundant modulation functions: AM, FM, PM, PWM, FSK; Linear/logarithm sweep and burst
Abundant output and input: Waveform output; Synchronous signal output; External modulation source, external 10MHz reference clock input, external trigger input and internal 10MHz clock output
Standard interface: USB Device, USB Host, LAN, RS-232 and GPIB; Support U-disc storage and Web remote control
Seamlessly interconnect with DS1000 series digital oscilloscope
Powerful arbitrary waveform editing software "UltraWave"
Support remote control via a command line
Clear graphical interface
Support Chinese and English menu
Button-help makes information getting easier
File management (support for U disc and local storage)
|
Model |
DG3121A |
DG3101A |
DG3061A |
|
Maximum Output Frequency |
120 MHz |
100 MHz |
60 MHz |
|
Output Channels |
1 |
|
Sample Rate |
300 MSa/s |
|
Arbitrary Waveform Length |
2 pts – 1 Mpts |
|
Resolution |
1 μ Hz |
|
Amplitude |
10 mVpp ~ 10 Vpp(50 Ω ), 20 mV ~ 20 Vpp(High Z) |
|
Amplitude Accuracy |
14 bits |
|
Standard Interface |
USB Host & Device, RS-232, GPIB(IEEE-488), LAN |
|
Optional Interface |
NO |
|
Product Category |
Desktop Function/Arbitrary Waveform Generator |
|
Dimension |
Width× Height× Depth=231mm× 108mm× 365mm |
|
Weight |
3.5 kg |
