Features:
1. Wide range of Chinese generator;
2. Reliable Performance;
3. OEM Service Offer;
4. Supper Silent.
|
Technical data |
|
Genset Model |
KH-100GF |
|
Prime Power |
100KW/125KVA |
|
Rated Power |
110KW/137KVA |
|
Rated Voltage |
230/380V |
|
Frequency |
50Hz |
|
Power Factor(COS) |
0.8(lagging) |
|
Dimension (L× W× H) (mm) |
3150× 1400× 2050 |
|
Genset weight (kg) |
2200 |
|
Diesel Engine |
|
Brand |
Cummins |
|
Model |
6BTA5.9-G2 |
|
Number of Cylinders |
6 |
|
Rotating Speed |
1500RPM |
|
Cylinder Arrangement |
Vertical in-line |
|
Cycle |
Four stroke |
|
Aspiration |
Natural Aspiration |
|
Bore× Stroke(mm) |
114× 135 |
|
Displacement(L) |
8.9 |
|
Compression Ratio |
16.0: 1 |
|
Speed Governor |
Electrical |
|
Cooling System |
Water-cooled |
|
Speed Stability (%) |
≤ 5% |
|
Total Lubrication System Capacity (L) |
24 |
|
Fuel Consumption at 100% Load |
182g/kwh |
|
Starting Method |
DC24V Electrical starting |
|
Alternator |
|
Brand |
STAMFORD |
|
Model |
UCI274D |
|
Number of Phase |
3 |
|
Connecting Type |
3 Phase and 4 Wires |
|
Number of Bearing |
1 |
|
Protection Grade |
IP23 |
|
Altitude |
≤ 1000m |
|
Exciter Type |
Brushless, Self-exciting, AVR automatic voltage regulating |
|
Insulation Class |
H |
|
Telephone Influence Factor (TIF) |
≤ 50 |
|
THF |
≤ 2% |
|
Voltage Regulation, Steady State |
≤ ± 1% |
|
Transient State Voltage |
≤ -15%+20% |
|
The components of the genset |
|
(1) CumminsDiesel Engine; (2)STAMFORDAlternator; (3) Automatic StartControl Panel; (4) Silent type with Base Fuel Tank |
|
Control Panel |
|
Kaihua AMF Control Panel choose the GU620B controller, the controller with large LCD display and adopts high performance computer chip, can modify control procedure and protection parameters of generator, which incorporating measure, control, portection and three remote functions and so on, an fully satisfactory different kinds of Genset auto control requirement for generator user and or special assembly factory. The controller measure and display all output digital parameters for generator, and rpm, oil pressure, water temperature, DC voltage and run time for engine. And the voltage and curren use real virtral value measure to make sure the data more exacter. |
|
Criterion |
|
(1) European Safety Standard: CE Certificate (2) ISO9001: 2008 Quality Control System |
|
Delivery Time |
|
Within 8 working days after get the deposit. |
Our company is maunfacturer of diesel generator, the OEM of cummins engines with certify of CE, ISO9001.
Mainly produce and sale diesel gen-sets, inland diesel gen-sets from 3-3000kVA, marine energent diesel gen-sets from 12-500kw and kinds of imported diesel gen-sets, movable power station, low-noise, multi-PCS connection, remote monitoring, gen-sets with ATS, gas gen-sets etc.
With good quality and low price.
