Cutting methods on the market today generally use oxygen and acetylene, propane, coke oven gas and other gases. Through experiment and practice, the use of hydrogen energy and water consumption will reduce the cost of forty percent lower than traditional methods to 60 percent.
Hydrogen gas is separated from the water electrolysis hydrogen and oxygen gas for industrial cutting.
Hydrogen machine has a ten-year lifetime. Calculated according to a decade, the use of hydrogen energy machine at least 3-5 times the cost savings, which is increased by 3-5 times for the use of units and profits in various fields.
Working principle
1. The principle is based on the theory of electrolysis.
2. It is consumed only water and electricity in the course of using.
3. To electrolyze water into pure hydrogen and oxygen.
4. Burning the gas then form Oxy-hydrogen flame.
5. Oxy-hydrogen flame is a high temperature energy source which can be used for precision cutting processing equipment, giving results that are economical, reliable, safe and environmental.
Why we use hydrogen machine
The hydrogen fuel comes from hydrogen generator, as compared with other fuels, has the following advantages:
1 Safety and environmental protection
1.1 The molecular weight of hydrogen is 2, is 1/14 lighter than air. Therefore, the leakage of hydrogen in the air will escape from the ground automatically without forming aggregates. But other oil and gas gathering ground will constitute explosive hazard.
1.2 Tasteless, non-toxic, does not cause intoxication, combustion products only water, do not pollute the environment.
2. High temperature energy
The heat of 1kg hydrogen is 34000Kcal, triple gasoline. Hydroxide flame's temperature is up to 2800 degrees, which is higher than conventional liquid gas.
3. Centralized heat
Oxy-hydrogen flame is straight, little heat loss and high efficiency.
4. Automatic regeneration
Hydrogen is from water, then reduced to water of combustion.
5 Variable -temperature characteristics
Flame regulation can be achieved according to the melting point temperature of the heated object.
6. Wide variety of sources
Hydrogen by electrolysis of water extraction, water is inexhaustible, and per kg water can produce 1860 liters hydrogen gas.
7. That production that is used
The use of advanced automatic control technology, machine hydroxide gas demand set by the user, not the storage of gas.
8 Wide range of applications: Suitable for all the needs of gas.
We can do OEM and also can design as your special request.
Welcome to visit our factory at any time in the future.
Product parameter
Model | Kingkar-3000 | Kingkar-5000 | Kingkar-7000 | Kingkar-10000 |
Voltage(V) | 380 ±10%,50/60Hz,three phase |
Rated capacity(KVA) | 9 | 15 | 22 | 31 |
Working pressure(Mpa) | ≤0.2 |
Relative humidity(%) | ≤90 |
Rated gas output(L/H) | 3000±10% | 5000±10% | 7000±10% | 10000±10% |
Water consumption(L/H) | 1.6 | 2.7 | 3.8 | 5.8 |
Maximum Cutting Thickness(mm) | 110 | 220 | 310 | 420 |
Effective perforated thickness(mm) | 40 | 60 | 70 | 90 |
Cooling way | Air cooling |
Insulation class | F |
power protection grade | IP2S |
Flame temperature(T) | 800-3200 adjustable |
Working medium | Filtered water or deionized water or soft water |
Working | continuous |
environment temperature(T) | 0-40 |
Dimension(L×W×H)mm | 1020*770*1270 | 1250*830*1720 | 1300*930*1820 | 1500*930*1940 |
Weight(KG) | 293 | 567 | 653 | 894 |
KingKar provides green energy solutions. We are specialized in Oxy-Hydrogen Generator, which changes soft water into a clean burning fuel that can be used to replace traditional gas fuels. We offer this safe, clean and pollution-free new source of green energy for mankind. Our development concept is based on creating a cleaner living environment around the world and promoting the use of sustainable energy sources.
KingKar Oxy-hydrogen generator for boiler only consumes water
And electricity to create oxy-hydrogen gas which feeds into to the combustion chamber for complete burning. It increases the combustion efficiency of the existing fuel etc. There is no pollution, no harmful gases or other chemical additives.
Our machine content: Oxy-hydrogen generator for boiler, Oxy-hydrogen used in industrial furnace, Oxy-hydrogen used in medical care, industrial And household wastes incinerator, Oxy-hydrogen used in generator, Oxy-hydrogen used in clean coal combustion technology, Oxy-hydrogen used in pharmaceutical industry and etc
