Our Advantages :
1. Reliable Performance:
Reliable Performance is the major advantage of Hi-earns products, and this reliability is based on the
outstanding design in every aspect and strict Q.C. System.
2. Customer First:
We devote ourselves to develop products to meet customers' requirements .Our engineer develop and
design new products for customers.
3. Technical Support and Service:our engineer team will solve your technical problems within 48 hours.
4. Strict test process before ex-factory :
Every product will be tested twice before ex-factory,and our products are 100% ex factory pass rate.
5. Certification: CE,ISO,,TUV,GS,SONCAP etc.
Warranty policy:
Guarantee for one year or 1000 hours whichever reach first from ex-factory date.
During the guarantee period, Hi-earns Power will provide the free easy-damageable spare parts of diesel
engine caused by our quality of production or raw material. After expiration, Hiearns Power provides cost
spare parts maintenance of gensets.
Our service:
1.Our quality department will provide the best solution that make you satisfied efficiently and accurately.
2.If the broken spare parts are in the period under warranty, we will offer this spare parts for free uncder
the condition of this spare parts are not intentionally damaged.
|
Hi-earns Generating Set Model |
GF- 150KVA |
|
Prime |
Standby |
|
Gen-set Power (KW/KVA) |
120/150 |
132/165 |
|
Engine Power (KW) |
132 |
|
Engine Model |
TBD226B-6D5 |
|
Engine Maunfacturer |
Sino-Germany joint venture Weichai-Deutz Co.,Ltd |
|
Engine Configuration |
6-cylinder in line,4-stroke, Exhaust gas Turbocharged,Air-to-Air cooled,direct spray fuel system |
|
Engine Cooling Mode |
The Radiator suitable for 40 degree Temperature,Strap drive the cooling fan with protection cover |
|
Speed Control System |
Mechanical speed controller,electricity-magnet valve control switch |
|
Start Mode |
Electric start |
|
Engine Filter System |
Dry air filter type,Fuel fifters,Lube filter |
|
Engine total displacement (L) |
6.23 |
|
Compress radio |
16.0:1 |
|
Bore× Stroke (mm) |
105×120 |
|
100% Load fuel consumption (L/h) |
30.3 |
33.4 |
|
Specific fuel consumption (g/kwh) |
≤ 198 |
|
Lubricating oil consumption (g/kwh) |
≤ 1.36 |
|
Exhaust Air Flow (m3/min) |
120 |
|
Air consumption (m3/min) |
9 |
|
Exhaust gas Flow (m3/min) |
19.75 |
|
Exhaust gas Temperature |
490 |
|
Oil Capacity (L) |
13 |
|
Coolant Capacity (L) |
27 |
|
Generator model |
Single bearing alternator |
|
Short circuit Protection |
MCCB Air switch |
|
Rated Voltage / Frequency / Power Factors |
400V/230V,50HZ , 0.8 lag , 3-phase & 4-line |
|
Stable Frequency Change Rate |
≤ 5% |
|
Free Load Voltage Adjusting Range |
≥ 95%-105% |
|
Stable Voltage Regulator |
≤ ±1% |
|
Insulation Class/Protection Grade |
H Class / IP23 |
|
Telephone Influence Factor |
TIF<50 / THF<2% |
|
Water tank ventilation area (mm) |
700×820 |
|
Dimension of open type (mm) |
2550×850×1800 |
|
Weight with fuel tank on base (kg) |
1500 |
|
Dimension of soundproof type (mm) |
3230 × 1170 × 1800 |
|
Weight with fuel tank on base (kg) |
2050 |
Changzhou Hi-earns Mechanical & Electrical Co., Ltd is established in 2005, which is a high-tech(mechanical&electrical) enterprise, gather "development, production, sales and systematic after-sales services" in one. Our company is certified by ISO9001-2008 QMS, get the EPA approval from U. S. A, CE approval from the European Union, GS approval from Germany and RoHS approval. Our company is one of the most influential enterprise in Eastern China, which is in the field of internal combustion engine.
Our company actively introduce advanced foreign technology and scientific management experience. The company have more than 300 staff, 50 of whom are junior and senior technicists, have 6 advanced automatic production lines. In addition, our company adhere to the brand strategy and international strategy, this greatly improved core competitiveness of us. Our main business includes: Water-cooled diesel generator set, air-cooled diesel engine and generator set, gasoline engine and generator set, water pump, minor agriculture machinery and road machinery equipment. Our company have developed out HR170FB which is turbine type air-cooled diesel engine with the own property right. What's more, this product have gained many certification of practical new-type patent. Our newly developed super silent generator set have got certification of invention patent, and we are the only factory which could produce it. Our company have strong technical force, and perfect after-sales service system. Our products have been sold to many main cities in China, and all over the world including North America, European, South America, Southeast Asia, Middle East, Africa, etc.
"Widely making friends with universal heart, positively returning society with responsible mind", this is the aim of Changzhou Hi-earns Mechanical & Electrical Co., Ltd. In the fierce competition environment, we all Hi-earns staff shoulder to shoulder, insist the faith of "surpassing ourself continuously, developing innovation constantly", and continuously strive for being the first brand of domestic and overseas in mechanical & electrical field, this shows Hi-earns unique enterprise charm and grace, which means "sincerity, diligence, cooperation, devotion". We will continue to build enterprise brand sincerely, gain customers' trust with quality, stand on domestic and overseas market with good price, open the future of Hi-earns with strong ability.
