Natural gas generator
1)LPG generator
2)closed water fan cooling
3)40kVA to 112kVA
4)CE approved
Natural gas generator and LPG generator with water fan cooling system CE approved (40kVA to 112kVA)
1. Brief Description
1) Adopting advanced Hall ignition sensor and Highly capable ignition system, the engine ignition will be more reliable, and easier to start.
2) Main control parts are all the most advanced imported ones, to make more stable and reliable running.
3) Several gensets can be parallel connection or parallel net, which can increase the total power range. In addition, the gensets can take maintenance in different times, which will make little influence to the normal performance of gensets.
4) Low gas pressure is acceptable, no need to set up specified gas storage tank, which will save the investment and enhance the efficient output power.
5) Economical and low-cost running.
|
Generating set Model |
PFO40-T |
PFO56-T |
PFO93-T |
PFO112-T |
|
Structure |
integral |
|
Exciting method |
AVR Brushless or Brush Excitation With AVR |
|
Rated Power (kW) |
32 |
45 |
75 |
90 |
|
Rated Current(A) |
57 |
81 |
135 |
162 |
|
Rated Voltage(V) |
400/230 (adjustable) |
|
Rated Frequency(Hz) |
50/60 |
|
Rated Power Factor |
0.8 LAG |
|
No load voltage setting range |
95%-105% |
|
Steady state voltage regulation rate |
≤ ± 1% |
|
Transient state voltage regulation rate |
≤ -15%— +20% |
|
Voltage fluctuation rate |
≤ 3s |
|
Steady state frequency regulation rate |
≤ ± 0.5% |
|
Transient state frequency regulation rate |
≤ ± 10% |
|
Frequency stabilization time |
≤ 5s |
|
Line-voltage waveform sinusoidal distortion rate |
≤ 2.5% |
Engine
|
Type |
OM4NG5-40G |
OM4NG5-55G |
OM6NG5-95G |
OM6NG5-115G |
|
Model |
In line, 4strokes , electric control ignition, pre-mixed stoichiometry burn |
|
Cylinder number |
4 |
6 |
|
Bore X stroke (mm) |
102x120 |
|
Total displacement (L) |
3.9 |
5.9 |
|
Rated Power (kW) |
32 |
45 |
75 |
90 |
|
Rated Speed (r/min) |
1500/1800 |
|
Speed Regulation Mode |
Electrical |
|
Starting Mode |
Electrical |
|
Fuel |
Natural gas or LPG |
|
MAX Gas Consumption (m3/h) |
10.4 |
14.5 |
24.1 |
29 |
|
Overall dimension (LXWXH)(mm) |
1760*780*1250 |
1840*780*1250 |
2130*800*1290 |
|
Net weight (kg) |
650 |
720 |
1020 |
1140 |
After over a decade´ S developing, Dalian Puyang Generating Set Co., Ltd. has become the leading generating set manufacture in Northern China. We have the largest scale of production and full product specifications and models. Puyang diesel generating set has past the test of China National Internal Combustion Set Quality Test Centre, we have also got the telecommunication facilities network import license of National Telecommunication Department and marine product certification of PRC, and we have been authorized by ISO9001 and WSSN2000 as well.
We have got long-term cooperation partners such as Cummins, Man, Volvo, Doosan, Mitsubishi, Shangchai, Weichai, Laidaong, Marathon, Engga, etc. With self-contained producing conditions, advanced testing equipments and abundant technologies, we can provide diesel generators from 8kw to 1800kw.
At present, we can supply standard diesel generator, automatic starting diesel generator, full automatic telemonitoring diesel generator, removable (mobile) power station, silent / soundproof diesel generator, weatherproof diesel generator, refrigerator car and marine product generating sets, etc. We have the only one full--function testing centre in Northern China, and we strictly follow the standard of GB/T2820 and ISO8528"AC generator set" to examine all functions of generating sets to guarantee 100% pass rate of our products.
