Aavantages
3/5 blades, 2 models for choice
Bearing from "SKF" Sweden
Stainless steel screw bolt from "THE"
Primary aluminum housing, not secondary aluminum
Low start-up wind speed
High-efficient generator
Perfect wind wheel system
Unique design of the rudder
Damp-proof, sand-proof, anti-rust, anti-corrosion
Easy installation, free of maintenance, long lifespan over 15 years
Parameters:
Rated power: 300 watts at 11 m/s
Max capacity: 350 watts
Voltage: 12, 24 VDC
Blades: 3pcs nylon fiber
Startup wind speed: 2.0m/s
Cut in wind speed: 2.5m/s
Rotor diameter: 1.16m
Weight: 6.2kg
Shipping dimensions: 790x 430x 220mm (8kg)
Mount: 1.9-inch (48mm) OD pipe
Body: cast aluminum
Over-speed protection: electronic torque control
Working temperatures: -20-120ºC
Certification: ISO 9001:2008, CE, RoHS
Survival wind speed: 50m/s
Warranty: 3 years
Stainless steel screw bolt from "THE" Primary aluminum housing, not secondary aluminum
Low wind speed series wind turbines generate more than 60% effective power than the same rotor diameter wind turbine annually
High-efficient generator: Three-phase permanent magnet synchronous wind turbine, more than 10% of the efficiency of ultra-GB, starting resistance, only be 1/3 of the GB limit, motor insulation rating class H insulation
Innovative noise reduction technology: Start and product electricity at the 1.5m/s, noise only at 40db at 13m/s
Perfect wind wheel system: The wind turbine wheels are made of a low temperature resistance, aging high strength compound material, can cope with a variety of complex wind conditions, charge wind energy into electrical energy efficiently and sustainably
Unique design of the rudder: Wind turbine rudders are ale to respond to the wind speed and wind direction flexibly, enhancing the efficiency of power generation
