Rated Power: 2000W
Wind wheel diameter: 3.3M/3.24M
Weight: 335KG
Blade Material: Aluminum Alloy
The number of blade: 3
Minimum wind speed start: 1.5m/s
Minimum power wind speed: 2m/s
Minimum charge wind speed: 3m/s
Rated wind speed: 13m/s
Maximum cut off wind speed: 15m/s
Resistant to wind speed limit: 60m/s
The type of Generator: Three-phase AC maglev wind turbine
Controller outputvoltage: 48V
Controller output current: <80AMP
Controller brake system: Over speed automatic
Three-phase short-circuit braking
Normal operating temperature: -40~50º C
Xinda Green Energy Co., Limited is specialized in handling the business of vertical and horizontal wind turbine generator, various kind of permanent magnet generator(0.05-3000kw), speed from 20rpm-20000rpm, both vertical and horizontal, small hydro turbine system(low head and higher head), wind solar hybrid system, high efficiency high seepd permanent magnet motor, street lamp and so on
