Lovol Generator set
Detailed Product Description:
Technical Specifications and of lovol Diesel Generator Set:
Techinical data
Genset model: GLW
Genset output Power range: 23KW~108KW
Rated Voltage: 50Hz: 400/230V 60Hz: 480/277V
Three-phase voltage available: 480/277V 440/254V 416/240V 220/127V 207/120V
Frequency: 50/60Hz
Power Factor(COS): 0.8
Rated Speed: 1500/1800RPM
Output Type: AC Three Phase/Single Phase
Inspiration Method: Natural aspirated or Turbocharged
Diesel Engine
Brand: Perkins Levol(Chinese)
Model: /
Engine Structure: 3L-6L
Cooling Method: Water cooled
Rotating Speed: 1500/1800RPM
Governor System: Electrical or Mechanical Governor
Aspiration mode Natural aspirated or Turbocharged
Starting method: 12/24V DC electric starting
Displacement(L): /
Bore× Stroke(mm): /
Compression Ratio: /
100%load fuel consumption(L/h): /
Alternator
Brand: Leroy semor, Stamford, Meccalte, Maraton etc.
Model: /
Excite Type: Brushless, AVR automatic voltage regulating
Connecting Type: 3 phase and 4 wires/single phase
Steady Frequency Change: 0~5%
No load voltage: ≥ 95%~105
Steady voltage: ≤ ± 1
Insulation degree: H degree
Exclosure degree: IP 23
The components of the genset
(1)Diesel engine; (2)Generator; (3)Control panel
The Accessories
Wave pipe, curved pipe, muffler, accumulator and the connecting line, shock-absorbing spacer, and data.
Control panel
The control panel is GZ6110 control panel, one controller, a key power switch, a DC power indicator, Emergency button,
According to customers requirment, can provide ammeter, voltmeter, frequency tables, etc,
Built-in the fine-tuning knob of speed and voltage,
Can be configured according to customer requirements or pre-warm the engine oil button
After 10 years of development, GTL company in energy generator industry has accumulated rich experience in manufacturing, the leading status. Headquarters is located in Xiamen, China.
Here, design, manufacture and sales of GTL brand series products and related technologies, and through the agency of global each country dealer network to provide customers with technical service. Products are widely used in office building, hospital, factories, municipal, power plants, university, entertainment. Besides, GTL can also according to customer special power needs to provide specific solutions for various industries and provide efficient and reliable electricity.
GTL production base in xiamen strictly enforce the ISO9000 quality and the industry standard, in order to ensure product outstanding quality.
