This series inverter is one of the most advanced D/C-A/C converters all over the world. Main advantage is, output high quality Sine Wave Inverter A/C electricity. Microcomputer control, humanization design, operate easily, work steady, no noise, and no pollute. It is suited to be used in the place without electricity, vehicle, ship, solar energy, windmill and so on.
The output A/C can supply the electricity to followed electric appliances: Such as several kinds of power tools, air-condition, electromotor, fridge, daylight lamp, TV set, fanner and so on.
|
Model |
SDP- 12KP |
|
Rated power |
12000W |
|
DC input voltage |
192V, (220V, 240V) |
|
Maximum discharge current |
62A |
|
Output current |
54A |
|
AC output waveform |
Pure sine wave |
|
Charge current |
10% according battery capacity |
|
Charge function |
Charger outside(can choose) |
|
Instant maximum power |
150% technical data, 10sec |
|
Output voltage |
110VAC, 220V AC ± 3% |
|
AC output frequency |
50Hz/60Hz± 0.05Hz |
|
No-load power |
0.8ADC |
|
Waveform distortion (THD) |
≤ 5%(Linear load) |
|
Inverter efficiency |
≥ 90% |
|
Work environmental temperature |
-10~60 |
|
Work environmental elevation |
≤ 1000m |
