Johndeere generator set, Johndeere generator
Detailed Description:
1. Engine: Johndeere
2. Alternator: Leroy Somer, Stamford or Marathon
3. Rated Voltage: 230V, 400V, 440V, 480V
Voltage available:
50Hz: 200/115, 220/127, 220/110, 230/115, 240/120, 380/220, 400/230, 415/240(200v--690v)
60Hz: 480//277, 440/254, 220/127, 240/139, 208/120, 120/240V
4. Power range: 24KW - 320 KW (30KVA-400KVA)
5. Rated Frequency: 50Hz
6. Rated Speed: 400V/1500RPM
7. Excitation way: Brushless Excitation
8. Inspiration method: Natural aspirated or turbocharged
9. Cooling Method: Water-cooled
10. Governor Method: Electrical or Mechanical governor
11. Cylinder: 3L-6L
12. Phase: 3pH-D / 3pH-C/F
13. Protection: IP23
14. Insulation Class: H
15. Stroke: 4 Stroke
16.8 hours operation tank
17. Key start/Auto start
18. Soundproof / weather-proof canopy is optional
19. Filter system: Oil, fuel and air filter
20. Accessories: Exhaust elbow, bellow, muffler
21. Supply standard collocation:
A)Diesel engine with all accessories, 3 filter, electric systems
B)Alternator
C)Steel structure
D)Fan and water tank cooling system
E)Flange connector
F)12/24 V starting motor and charge engine
G)Air cleaner, fuel cleaner, oil cleaner
H)On-board control panel
I)MCCB air conservation switch
J)12/24V starting accumulator and Battery line
K)Set shock absorber
L)High-efficient silencerlnner
22. AMF, ATS, Soundproof canopy and movabel trailers for choices.
23. Standard: CE and ISO9000, ISO14000
24. Standard export packaging or as customers requirement
| Brand Name | GTL |
| Model Number | GJW |
| Place of Origin | Fujian, China (Mainland) |
| Output Type | AC Three Phase |
| Speed | 1500/1800 |
| Frequency | 50/60 |
| Rated Power | 34-440KVA |
| Rated Voltage | 220/230/380/400/480V |
| Advantage 4 | Could make parallel connection |
| Advantage 3 | Could make full power solution |
| Engine | Johndeere |
| Cylinder | 3L-6L |
| Standard | CE and ISO9001&14000 |
| Protection | IP23 |
| Altenator 1 | Leroy somer/Mecc alte |
| Altenator 2 | Marathon/Stamford |
After 10 years of development, GTL company in energy generator industry has accumulated rich experience in manufacturing, the leading status. Headquarters is located in Xiamen, China.
Here, design, manufacture and sales of GTL brand series products and related technologies, and through the agency of global each country dealer network to provide customers with technical service. Products are widely used in office building, hospital, factories, municipal, power plants, university, entertainment. Besides, GTL can also according to customer special power needs to provide specific solutions for various industries and provide efficient and reliable electricity.
GTL production base in xiamen strictly enforce the ISO9000 quality and the industry standard, in order to ensure product outstanding quality.
