Principle of operation
LUnder the effect of high efficiency catalyst, nitrogen reacts with Hydrogen source accessed to system, after removing residual oxygen, then further dehydrogenation, entering into drying system depth dehydration, at last we get high purity nitrogen.
L
Technical characteristics
L1. Automatic control hydrogenation quantity, owning high degree of automation, Safe and reliable.
L2. Choose high efficiency catalyst, it has advanced technology, and stable performance.
L3. Use safe and reliable control components, operate reliable.
L4. Intelligent interlocking vent and various fault alarm, making the user find and solve problems in time.
L
Technology index
LNitrogen output: 10-3000NM3/H
LNitrogen purity: ≥ 95-99.999%
LDew point: ≤ -60° C
LOxygen content: ≤ 5 PPM
LType Hydrogen content: 500-5%(adjustable)
LTypeHydrogen content: ≤ 5 PPM
|
Model |
Rated Gas processing |
Output |
hydrogen Consumption |
Installed power |
cooling water |
|
((Nm3/h)) |
(Nm3/h) |
(Nm3/h) |
(kw) |
(t/h) |
|
KHN—10Ι |
11 |
10 |
0.15 |
1 |
0.2 |
|
KHN—20Ι |
22 |
20 |
0.3 |
1 |
0.4 |
|
KHN—40Ι |
44 |
40 |
0.45 |
1.5 |
0.6 |
|
KHN—60Ι |
66 |
60 |
0.7 |
1.5 |
0.75 |
|
KHN—100Ι |
110 |
100 |
1.2 |
2 |
1.35 |
|
KHN—150Ι |
165 |
150 |
1.7 |
3 |
1.75 |
|
KHN—200Ι |
220 |
200 |
2.3 |
5 |
2.1 |
|
KHN—300Ι |
330 |
300 |
3.4 |
6 |
3.1 |
|
KHN—400Ι |
440 |
400 |
4.5 |
7 |
4.3 |
|
KHN—500Ι |
550 |
500 |
5.6 |
9 |
5.2 |
|
KHN—10ΙΙ |
11 |
1 |
0.15 |
2.5 |
0.4 |
|
KHN—20ΙΙ |
22 |
20 |
0.3 |
3.5 |
0.8 |
|
KHN—40ΙΙ |
44 |
40 |
0.45 |
4.5 |
1.2 |
|
KHN—60ΙΙ |
66 |
60 |
0.7 |
6 |
1.5 |
|
KHN—100ΙΙ |
110 |
100 |
1.2 |
9 |
2.7 |
|
KHN—150ΙΙ |
165 |
150 |
1.7 |
12 |
3.5 |
|
KHN—200ΙΙ |
220 |
200 |
2.3 |
18 |
4.3 |
|
KHN—300ΙΙ |
330 |
300 |
3.4 |
25 |
6.2 |
|
KHN—400ΙΙ |
440 |
400 |
4.5 |
32 |
8.6 |
|
KHN—500ΙΙ |
550 |
500 |
5.6 |
37 |
10.5 |
Note: the design standards of this table is as below:
Environment temperature:0°C,0 meter elavation,cooling water temperature:32°C,inlet nitrogen purity:99.5%.
|
Hangzhou Juke Air Separator Installation Manufacture Co., Ltd. is a high-tech enterprise established in 2008. We are specialized in the research, development and manufacture of nitrogen generators, oxygen generators, compressed air dryers, and so on. Our products are widely applied to petroleum chemical, metallurgical coal, electronic electricity and biomedical industries.
We have a professional and experienced technical development team which is willing to design and manufacture products with both standard and customized specifications. All of our products must be 100% tested to ensure their functionality, reliability, security and durability before shipment.
During the past few years, our priority has always been "customer services and customer satisfaction". We have done a lot to raise our quality level and have striven to establish a sound quality management and guarantee system. Furthermore, our company has attained ISO9001: 2008 Quality Management System certificate.
By virtue of excellent energy saving technologies and unremitting efforts of Juke people, we have reasons to believe that Juke will become the technology leader in this industry. Quality is our life, prestige is our basis and service is our cornerstone! Juke is willing to work hand in hand with friends from all circles to create a bright future.
