The unique articulated hydraulic mast is ideal for the mining industry, as well as use on railroad, municipal and large construction sites.
Features:
1. Articulated hydraulic mast provides maximum flexibility and control for quick, effortless light positioning.
2. 28 foot vertical, 20 foot horizontal outreach and 360° Power rotation.
3. 8 foot 2 inch stowed length provides for ease of transport for towing or transportation on a trailer or container.
4. Optional environmental spill containment to meet local regulations or for use in sensitive areas.
5. Light fixtures plug in weatherproof receptacles box at top of tower with CE approved connectors.
6. Individual plug-in ballasts installed in galvanized steel boxes. Can be replaced without disconnecting wiring terminals.
7. Control panle is inside, away from the elements. Houses main and branch circuit breakers and hourmeter.
8. Gavanized outriggers with pre-set position stops ensure quick and proper spacing.
9. Single point lifting eye and forklift pockets provides for easy loading and unloading.
10. Optional Australian mining configuration designed specially to meet Australian regulations and mining application requirements.
Description:
Engine: Vertical, water cooling, four stroke
Make/model: Km385d
Cooling: Water
Kw(HP) at continuous: 12(16)/17(23)
Revolution(rpm): 1500/1800
Fuel capacity(liter): 100
Contineious run time: 60hours
Number of cylinders: 3
Displacement l(cu, in): 1.532
Engine shutdown protection: Low oil pressure, hight water tempreture, hight oil tempreture, over speed
Exhaust gas emmission: EPA approval optional
Alternator
Make/model: Brushless tfdw-8kw/10KVA
Output: 8kw/10KVA
Frequency: 50/60
Insulation: H
Type of bearing/brush: Single/brushless self excitation
Available receptacles: 220v/45a
Lighting: Metal halide, single ended, 1000w
Brand
Type of lamp: Metal halide, single ended
Lamp no.: 4-8
Housing materials: Aluminum reflector housing
Mast tower
Type: Multi-sections telescoping hydraulic mast 9 m
Total height: 9m, can be rotaed 360 degree
Operate for extends: Hydraulic drive mast
Traveling: Retracts and stows horizontally for travel tower is locked into position to prevent during travel
Outriggers: Hydraulic outrigger no. 4
Trailer/cabin: With the outriggers extended and all jack down
Towing type: Ring hitch
Cabin: With two doors access for easy maintenance with hanger for handling detachable roof
Electric-shutdown protection
Electric: MCCB-MCB emergency stop IP 56
Our company is a professional manufacture of general engines, generator sets, light towers and construction machinery. Our technicians have ten years work experience in the machinery field.
We are making efforts to supply quality products and good service for our customers. Welcome to visit us!
