Hydraulic Generator/ hydro generator/ water generator
The generator is mainly used in hydro-power generation.
It can form a hydro generator unit in association with hydraulic turbine,
and be used in small- and medium-sized hydro power stations with varied water head
and flow rate, or capacity expansion and reform of existing power stations as well
The standards for design and production of the generator mainly include:
GB755-2008 Rating and Performance of Rotary Motor
GB14711-2006 Safety Requirements of Small- and Medium-Sized Rotating Electric Machine
GB/T7894-2001 Fundamental Technical Specifications for Hydro Generators
|
No. |
Item |
Specification |
|
1 |
Brand name |
Wa Wu Shan |
|
2 |
Frequency |
50HZ 60HZ |
|
3 |
Installed capacity |
50-20000KW |
|
4 |
Color |
Grey, Green, Yellow, Blue |
|
5 |
Synchronous generator |
3-phase, AC alternator |
|
6 |
Power grid |
11KV, 10.5KV, 35KV, 38KV, 65KV |
|
7 |
Runner material |
ZG0Cr13Ni4Mo |
|
8 |
Exported countries |
Albania, Turkey, Nepal, Vietnam, Peru... |
|
9 |
Model number |
HLA130-WJ-97 |
SFWE-K-5000KW-8/2150 |
|
HLA542-WJ-100 |
SFWE-K-3200KW-8 |
|
HLA575C-WJ-60 |
SFWE-K-1000KW-6/1180 |
|
HLA194-WJ-84 |
SFWE-K-3200KW-8/1730 |
|
HLD50-WJ-57 |
SFWE-K400-6/850 |
|
HLA708A-WJ-53 |
SFWE-K-400-6/850 |
|
HLD307C-WJ-64 |
SFWE-K1400-6/1180 |
|
HLA696-WJ-68 |
SFWE-K-2500KW-8/1730 |
|
HLA253-WJ-71 |
SFWE-K-3200KW-6/1730 |
| Prod Model: |
SFWE-K1000-6/1180 |
| Markets: |
South America,Eastern Europe,Southeast Asia,Africa,Mid East,Eastern Asia |
| Sfwe: |
Two-Fulcrum Turbine Generator |
| W: |
Horizontal Arrangement of Main Shaft |
| K: |
Static Silicon Controlled Excitation Device |
| 1000: |
Output Capacity Is 1000kw |
| 6: |
6 Magnetic Poles |
| Rotating Speed: |
1000rpm |
| 1180: |
Outer Diameter of Generator Stator Core |
| Rated Voltage: |
6300V |
Hongya Power Generating Equipment to Utilities Limited, is a professional manufacturer of hydro power generating equipments. It has high quality products include mainly water turbine, generator and governor. Water turbines units with an individual capacity of 50kw~20000KW, we have jet turbines, Pelton turbines, Francis Type turbines, and axial turbines. All these products are produced and tested according to national standards, and machinery trade standards. The products have such characters as rational structure, reliable operation, high efficiency, standardized spare parts, high generalization, and convenient maintenance. They are available in every variety and model, and have reliable quality.
Hongya Power Generating Equipment to Utilities Limited has obtained the certification of ISO9001/2008, SGS certificate and is the member of Chinese Society of Electrical Industry. Products are sold all over China and exported to Albania, Nepal, Indonesia, Turkey, Vietnam and Myanma, etc
Stepping into the past and looking forward to the future, we will continuously strengthen the innovation on products and techniques, strictly control the product quality and build up more perfect after-sale service system.
