1. Coupled to a reliable and fun cooling diesel engine so it is compact in structure, light in weight, low fuel consumption and convenient for operating
2. Low oil shutdown stops the engine immediately when the lube oil drops below a safe level so it can avoid to the damage and loss.
3. Durable-4sheel rolling structre fortability and operating indoors of outdoors.
4. No fuse circuit breaker provides overload protection.,
5. Iarge fuel tank ensures hours of continuous running.
6. Inside it is coupled to high efficient noise-proof materials, vibrations-Reducing structure combine to form a silent machine.
| Model | GFS-8 | GFS-10 | GFS-12 | GFS-15 | GFS-20 | GFS-24 | GFS-30 | GFS-40 | | Engine | POWER(kw/KVA) | 8(10) | 10(12.5) | 12(15) | 15(18.75) | 20(25) | 24(30) | 30(37.5) | 40(50) | | Engine Model | YSAD380G | YD480G | YND480G | YS490G | Y4100G | Y4100G | ZH4105D | R4110D | | Engine Power | 10 | 13 | 15 | 19 | 25 | 30 | 35 | 49 | | Speed(r/min) | 1500/1800 | | Starting method | Electric starting | | Cooling method | Closed water cooled | | Governing method | Mechanical | | Intaking method | Natural aspirated | | Fuel consumption(g/lw.h) | ≤247 | ≤262.5 | ≤247 | ≤247.5 | ≤237 | ≤238 | ≤231 | | Generator | Generator Model | STC-8 | STC-10 | STC-12 | STC-15 | STC-20 | STC-24 | STC-30 | STC-40 | | TFW-8 | TFW-10 | TFW-12 | TFW-15 | TFW-20 | TFW-24 | TFW-30 | TFW-40 | | Rated output(kw) | 8 | 10 | 12 | 15 | 20 | 24 | 30 | 40 | | Rated Voltage(V) | 400/230 | | Rated Current(A) | 14.4 | 18 | 21.7 | 27.1 | 36 | 43.2 | 54 | 72 | | Frequency(HZ) | 50/60 | | Power Factor | 0.8 lagging | | Phase/Connection | 3-phase 4-wire,Y-type connection | | Excitation | Harmonic or Brushless Excitation | | Voltage | Manual/Automatic | | Net weight | 690 | 720 | 750 | 800 | 860 | 870 | 1100 | 1200 | | Packing Size LWH(cm) | 175×97×109 | 175×97×109 | 175×97×109 | 195×103×119 | 205×103×119 | 205×103×119 | 215×106×135 | 225×106×135 | | | Specifications given herein are subject to change without notice | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | Main Specification | | | | | | | | | | Model | GFS-50 | GFS-75 | GFS-100 | GFS-120 | GFS-150 | GFS-200 | GFS-250 | | | Engine | Power(kw/KVA) | 50(62.5) | 75(93.75) | 100(125) | 120(150) | 150(187.5) | 200(250) | 250(312.5) | | | Engine Model | R41205ZD | R6105ZD | R61051ZLD | R61051ZLD | G128ZLD | G125JZD | 12V135AZD | | | Engine Power | 56 | 84 | 110 | 132 | 187 | 236 | 35 | | | Speed(r/min) | 1500/1800 | | | Stsrting method | Electric starting | | | Cooling method | Closed water cooled | | | Governing method | Mechanical | | | Intaking method | Turbocharged | | | Fuel consumption(g/lw.h) | ≤231 | ≤224 | ≤218 | ≤225 | ≤231 | ≤231 | ≤228 | | | Generator | Generator Model | STC-50 | SPL-32 | SPL-34 | SPL-35 | SPL-41 | SPL-43 | SPL-44 | | | TFW-50 | | | Rated output(kw) | 50 | 75 | 100 | 120 | 150 | 200 | 250 | | | Rated Voltage(V) | 400/230 | | | Rated Current(A) | 90 | 135 | 180 | 316 | 170 | 360 | 450 | | | Frequency(HZ) | 50/60 | | | Power Factor | 0.8 lagging | | | Phase/Connection | 3-phase 4-wire, Y-type connection | | | Excitation | Harmonic or Brushless Excitation | | | Voltage | Manual/Automatic | | | Net weight | 1300 | 1500 | 2600 | 2950 | 3050 | 3700 | 3850 | | | Packing Size LWH(cm) | 232×106×135 | 270×110×140 | 330×130×165 | 370×138×179 | 395×145×190 | 400×180×205 | 420×180×210 | |
|
| |
Mindong Baiyun Electrical Machine Co., Ltd., is an export base enterprise of electric and mechanical products approved by National Economic and Trade Committee. It is one of 15 top electic motor and appliance enterprises in Mindong and a major taxpaying company in Fuan. It specializes in the production and export of series of electric generators, diesel oil power supply units and series of water pumps. Since its estalishment, sticking to the guideline of 'Seek development by science and technology, seek survival by quality, seek profit by management', the company has been developing rapidly by paying greet attention to product development and quality management. 100% of its products are exported to Southeast, Asia, Middle East, South America, Europe, The United States and othercounties and regions. Its electric motor for pumps passsed the national security certification of electric produxts in 1996. ST ans STC series of electric generators have passed departments and have been granted quality license of export participated in the Egypt International Fair and were granted the Pyramid Prize.
To strengthen the management and raise the corporate scale, the Company pays great attention to recruiting and introduction oftechnical talents. Introducing technical cadre-mem for within and ourside the province, the companu now has 4senior engineers, 8 engineers and 16 technical persons, which constitutes the Technical Development Department and enables the company to increasethe scientific and technolohical contecnts of its products and make contribution to the development of new products. There are workshops of generator, water pump and metalworking. 8 new production lines have examing equipment have been introduced to strengthen quality inspection and standardize production and management, move of working procedure and product export.
We are ready to meet coming guests from all sides with brand new looks, superior quality and service.
