A: DIESEL GENERATOR SET STANDARD SCOPE OF SUPPLY
Our generator will be equipped with the following scope of supply:
1) Brand new Wudong engine ( Made in China)
2) Brand new Stamford / Marathon, AC brushless alternator ( USA, Factory in China)
3) Control Module GCM338 ( Made in Hong Kong)
4) Circuit breaker
5) Rubber isolator for engine, alternator and control panel
6) 24V Battery with battery cables and rack
7) Industrial silencer
8) 8 hours Fuel tank with fuel gauge integrated in the base frame of generating set
9) Standard tools kit
10) English operation/maintenance manuals
11) Quality Certifications
12) Warranty against manufacturing defects shall be covered in a period of 18 months or 1200 running hours whichever comes first
B: DIESEL GENERATOR SET ENGINE MODEL: WD150D15
1) Brand: Wudong
2) Cooling Mode: Water Cooled
3) Rotation: 1500RPM or 1800RPM
4) Turbocharged with cooling fan, water cooling tank, 24V electric starting system
5) Overspeed Capacity: 120%
6) Overload Capacity: 110%
7) Fuel: Diesel
C: DIESEL GENERATOR SET ALTERNATOR MODEL: UCI274F/MP-120-4
1) Brand: Stamford / Marathon
2) Specifications: 50Hz OR 60Hz (avilable), 400/230V, 3 Phase / 4 Line, PF: 0.8
3) Wave Distort: Less than 10%
4) Electric System: 24V
5) Volt Fluctuation: Less than 0.5%
6) Type: H-class insulation, IP21-IP23 protection, Direct Coupled, Brushless, Synchronous, AVR
D: DIESEL GENERATOR SET CONTROL PANEL
1) Controller System: GCM 338 Automatic engine shutdown protection capability with LED indicator for low oil, high engine temperature, overspeed and failure to start.
2) Control Panel
Contains voltmeter, tachometer, hour meter, frequency meter, fuel level indicator, engine temperature gauge, charging gauge and MCCB
E: DIESEL GENERATOR SET SOUNDPROOF CANOPY
1) 68 to 70dB(A) at 7 metre
2) Colour of canopy: Orange ( We may be able to provide the colour that you may prefer)
