Generator:
Type: Brushless, self-exciting, 2-poles, revolving mannetic field, 1phase
Frequency (Hz): 50/60
Rated voltage(v): 110, 115, 120, 220, 230, 240, 110/220, 120/240
Max. Output(kw): 2. 3/2. 5
Rated output(kw): 2. 0/2. 2
Power factor: CosΦ =1. 0
Engine:
Model: GH168FD
Type: Forced air-cooled, 4-stroke, OHV, one cylinder
Displacement(ml): 163
Max. Output(kw): 5. 5HP/3600RPM
Fuel: Unleaded gasoline
Fuel tank caperation hours(h): 12
Continuous operation hours(h): 12. 0/10. 0
Oil: Engine oil SD or higher(A. P. I)SAE10w/30w
Oil alert: Optional
Oil capacity: 0. 6
Lgnition sysem: T. C. L
Starting system: Recoil
Noise level db(a): 66/69
Dimension:
Net dimension(L*W*H)(mm): 545*425*440
Overall dimension (L*W*H)(mm): 560*440*460
Net weight(kg): 43
Dry weight(kg): 45
Branch manfachurer: Taizhou Haofeng Industrial &Commercial Co., Ltd.
A manufacturer specializing gasoline generator, diesel generator, gasoline water pump, gasoline chain saw, gasoline cut-off saw, gasoline brush cutter, gasoline hedge timmer.
With ISO9000, CE, EPA, ROSH.
