Standard Equipment:
Frame/machine Cover(all Frame),Volt,Meter,Circuit Breaker,Engine Oil warning system,Big Air Cleaner,Avr Type,A.C.Machine Annex
Engine | Engine Model | HC-168F | HC-168F-1 | HC-170F |
Model | 5.5HP | 6.5HP | 7.0HP |
Engine Type | (Air-cooled;4-stroke;OHV,single cylinder) |
igniting System | Transistor magneto |
Starting System | recoil/Electric |
Displacement | 163cc | 196cc | 210cc |
Max.Output | 4.1kw | 4.8kw | 5.1kw |
Fuel tank capacity | 15L | 15L | 15L |
Continuous operating time | 13h | 12h | 10h |
Min.Fuel Consumption | 360g/kw.h | 360g/kw.h | 360g/kw.h |
Noise level | 65dB | 67dB | 69dB |
Lube.oil capacity | 0.6L | 0.6L | 0.6L |
Generator | A.C.frequency | 50/60HZ |
Rated Voltage | 110/220V |
Max.A.C.output | 2.2kw | 2.8kw | 3.0kw |
Rated.A.C.output | 2kw | 2.5kw | 2.8kw |
Size&Weight | Dimension(LxWxH) | 725x445x450mm | 605x445x450mm | 605x435x450mm |
Net weight | 40kg | 43kg | 45kg |
All the above designs are available for 2kw,2.5kw,2.8kw |
