4. Application principles
4.1 The wind turbine should be installed in an open and flat area without barriers nearby.
4.2 Off-grid wind turbine generating electric power is charged to the batteries group. When there is no wind, it consumes the electricity from the battery group. Therefore, after discharging, the batteries should be recharged timely, especially for lead-acid batteries. During the working, over discharging, over charging or after over discharging, the batteries cannot be recharged timely, the working life of the batteries will be reduced in above conditions. So, the users should regulate the consuming capacity of the electricity according to local wind condition and the electricity capacity generated by the wind generator.
4.3 After passing full wave bridge rectification, the 3-phase AC electricity generated by wind generator is output with DC power, usually are DC24V, 36V, 48V, 120V. The voltage of the battery group should be equal to the DC voltage of the wind generator (after rectification).
4.4 The input DC voltage of the matched inverter should be equal with working voltage of the wind generator (after rectification).
We supply: Wind turbinwind generator, wind power generator, wind turbine generator, small wind generator, marine wind generator, wind powered generator, wind generator plans, DIY wind generator, homemade wind generator.
|
Rotor Diameter (m) |
4.0 |
|
Material and number of the blades |
Reinforced fiber glass*3 |
|
Rated power/maximum power |
3000/3800w |
|
Rated wind speed (m/s) |
12 |
|
Startup wind speed (m/s) |
2.5 |
|
Working wind speed (m/s) |
3~35 |
|
Survived wind speed(m/s) |
50 |
|
Rated rotate speed(r/min) |
350 |
|
Working voltage |
DC48V/120V/240V/300V/350V |
|
Generator style |
Three phase, permanent magnet |
|
Charging method |
Constant voltage current saving |
|
Speed regulation method |
Yaw+ Auto brake |
|
Weight |
85kg |
|
Tower height (m) |
12 |
|
Suggested battery capacity |
12V/200AH Deep cycle battery 12pcs |
|
Life time |
15years |
