Specifications
10 years lifetime, durable to use-Brown gas generator for boiler
1. High efficiency low cost
2.10 years lifetime
3.24 hours none stop working
4. Manufacture, low price
Oxygen Hydrogen generator Introduction:
Water is H2O, under some circumstances, if electrolysis water, it could give out H2 and O2. Hydrogen is a quite good fuel material, in normal uses, oxygen helps hydrogen to burn into water again. Whole process is quite clean, no pollution.
Our Machine Features:
1. High working efficiency:
2. Environment Protection:
3. Economic
4. High technology high precision
5. Easy use
6. Very Safety
Application of oxyhydrogen generator for boiler:
1. Welding
(1) Jewelry Industry:
(2) Electronic Industry:
(3) Medical Industry:
(4) Laboratory:
(5) Others:
2. Heating and sealing
(1) metal and nonmetal heating
(2) glass tube sealing, quartz glass tube sealing
(3) ampoule bottles sealing
(4) water injection drawing sealing
(5) mould repair, quenching, crucible heating melting metal
(6) solar wafer processing, IC packaging
For welding work, kater oxyhydrogen generator has below advantages compared with other welding methods:
1. Operation is convenient:
Oxyhydrogen generator produce oxy-hydrogen gas by automatic way, gas cylinder is not required any more. Turn on to produce gas and shut down to stop producing. Machine will shut down automatically when the gas pressure is too high (if gas output can not be used up). Machine will turn on auto when the gas pressure is not enough. The gas output is adjustable.
2. Welding is fast:
The oxy-hydrogen flame temperature is high up to 2800 degree, it can heat the welding spot to melting point fast in about 1 second to finish welding.
3. Welding precision is high:
The flame is concentrated, it can achieves welding of precise devices.
4. Welding spot is smooth and beautiful:
Oxy-hydrogen flame combustion doesn't form carbide, so there is no black spot, avoid the second treatment of cleaning and polishing.
5. Environment friendly: Oxyhydrogen Generator's fuel comes from water, there is water vapor after combustion, no any harm done to environment.
6. Energy saving:
Oxyhydrogen generator saves energy cost over 30% compared with other gas welding way. Adding the oxygen cost, it will save cost over 40%.
Technical Data Sheet of Kingkar oxy-hydrogen generator in boiler combustion:
Model | Kingkar-3000 | Kingkar-5000 | Kingkar-7000 | Kingkar-10000 |
Voltage(V) | 380 ±10%,50/60Hz,three phase |
Rated capacity(KVA) | 9 | 15 | 22 | 31 |
Working pressure(Mpa) | ≤0.2 |
Relative humidity(%) | ≤90 |
Rated gas output(L/H) | 3000±10% | 5000±10% | 7000±10% | 10000±10% |
Water consumption(L/H) | 1.6 | 2.7 | 3.8 | 5.8 |
Cooling way | Air cooling |
Insulation class | F |
power protection grade | IP2S |
Flame temperature(T) | 800-3200 adjustable |
Working medium | Filtered water or deionized water or soft water |
Working | continuous |
environment temperature(T) | 0-40 |
Dimension(L×W×H)mm | 1020*770*1270 | 1250*830*1720 | 1300*930*1820 | 1500*930*1940 |
Weight(KG) | 293 | 567 | 653 | 894 |
Thank you for visiting. Any questions, please feel free to contact us. I am Mr.Huang Renhua here.
KingKar provides green energy solutions. We are specialized in Oxy-Hydrogen Generator, which changes soft water into a clean burning fuel that can be used to replace traditional gas fuels. We offer this safe, clean and pollution-free new source of green energy for mankind. Our development concept is based on creating a cleaner living environment around the world and promoting the use of sustainable energy sources.
KingKar Oxy-hydrogen generator for boiler only consumes water
And electricity to create oxy-hydrogen gas which feeds into to the combustion chamber for complete burning. It increases the combustion efficiency of the existing fuel etc. There is no pollution, no harmful gases or other chemical additives.
Our machine content: Oxy-hydrogen generator for boiler, Oxy-hydrogen used in industrial furnace, Oxy-hydrogen used in medical care, industrial And household wastes incinerator, Oxy-hydrogen used in generator, Oxy-hydrogen used in clean coal combustion technology, Oxy-hydrogen used in pharmaceutical industry and etc
