Frequency(Hz): 50/60
Max. AC output(KVA): 4.5/5.3
Rated AC output(KVA): 4.2/5.0
Rated AC Voltage(V): 110, 220, 230, 240, 110/220V, 120/240V
Power Factor(cosφ) 1.0
Type: Brushless, self-excitation, 2-poles, Single-phase
Voltage Regulator: Condenser Type
DC Output: 12V/8.3A(option)
Engine Model: DH186FDE
Type: Forced air-cooled, 4-stroke, Diesel Engine
Displacement(cc): 406
Max. Output(Hp/rpm): 10.0/3600
Fuel: Diesel Light Fuel
Fuel Tank capacity(L): 16
Continuous Operating Hours(H): 9.5/8.5
Oil: SAE 10W30(Above CC grade)
Oil capacity(L): 1.65
Ignition System: Direct injection
Starting System: Electric start
Operating Noise Level(7m)db(A): 69/70
Net Dimension LXWXH(mm): 910x520x680
Overall Dimension LXWXH(mm): 950x565x770
N. W. /G. W. (kg): 161/171
20GP/40GP/40HQ: 48/96/144
Yongkang Qinyuan Industry Co., Ltd. Established in 1999, Yongkang Qinyuan Vehicle Manufacture Co., Ltd. Is a specialized manufacturer of ATV quads, go karts, dirt bikes, mini choppers, golf carts. Meanwhile, we also provide OEM service to better fulfill customers' specifications.
From year 2001, we started producing high quality interior doors, non-standard doors with our technology. Also We introduced the most advanced production equipment and technology, and have the capability of design and development.
Having focused on the improvement of quality control system and enhancement of scientific management, we have obtained more opportunities and competitive advantages in both domestic and foreign markets. Moreover, we can satisfy customers' changing needs through the research and development of innovative products.
Providing 'Quality Products, Excellent Service, Competitive Prices and Prompt Delivery', we are now looking forward to even greater cooperation with overseas customers based on mutual benefits. Please feel free to contact us or visit our website for more information.
