Frequency(Hz): 50/60
Max. AC output(KVA): 5.5/6.5
Rated AC output(KVA): 5.0/5.5
Rated AC Voltage(V): 110, 220, 230, 240, 110/220V, 120/240V
Power Factor(cosφ): 1.0
Type: Brushless, self-excitation, 2-poles, Single-phase
Voltage Regulator: Condenser Type
DC Output: 12V/8.3A(option)
Engine Model: XY188F
Type: Forced air-cooled, 4-stroke, OHV
Displacement(cc): 389
Max. Output(Hp/rpm): 13.0/3600
Fuel: Unleaded Gasoline
Fuel Tank capacity(L): 22
Continuous Operating Hours(H): 8.2/7.5
Oil: SAE 10W30(Above CC grade)
Oil capacity(L): 1.1
Ignition System: T. C. I
Starting System: Recoil
Operating Noise Level(7m)db(A): 75/77
Net Dimension LXWXH(mm): 674x510x532
Overall Dimension LXWXH(mm): 690x525x550
N. W. /G. W. (kg): 84/87
20GP/40GP/40HQ: 140/292/292
