Rated frequency (Hz) 50 60
Rated voltage (V) 230 240/120
Rated current(A) 13.0 14.1/28.3
Rated output power (kW) 3.0 3.4
Rated rotation speed(rpm ) 3000 3600
DC output 12 V/8.3A
Power factor(cosφ) 1.0
Phase number Single phase
Noise level[Db(A)@7m] 72
Dry weight [kg(lbs.)] 64(141)
Structure type Open-frame type
Coupling mode Rigid couping by rotor drive shaft
Engine model LD178FAG
Engine type Singlecylinder, 4-stroke, air-cooled, direct injection, diesel engine
Displacement[ml(cu.In)] 308(18.79)
Compression ratio 20: 1
Rated power (kW(HP)/rpm) 3.9(5.30)/3000
Starting system Recoil starter
Rotation direction(View from flywheel) Clockwise
Lube SAE10W30 (above CC grade)
Low oil pressure alert system
FUZHOU LINGLI POWER Co., Ltd. located in FUZHOU FUJIAN, a famous town of oversea was founded in the early of 2004. Occupying more than 50, 000 square meters, we have more than 270 employees, and more than 30% among them are high technical researchers
We are a professional manufacturer specialized in highly technical power generator as the following series products line:
