Rated frequency (Hz) 50 60
Rated voltage (V) 230 240/120
Rated current(A) 7.4 8.3/16.7
Rated output power (kW) 1.7 2.0
Rated rotation speed(rpm ) 3000 3600
DC output 12 V/8.3A
Power factor(cosφ) 1.0
Phase number Single phase
Noise level[Db(A)@7m] 72
Overrall dimension
(L x W x H)[mm(in)] 625 x 455 x 520(24.60 x 17.91 x 20.47)
Dry weight [kg(lbs.)] 54(118)
Structure type Open-frame type
Coupling mode Rigid couping by rotor drive shaft
Engine model LD170FG
Engine type Singlecylinder, 4-stroke, air-cooled, direct injection, diesel engine
Displacement[ml(cu.In)] 211(12.88)
Compression ratio 20: 1
Rated power (kW(HP)/rpm) 2.5(3.4)/3600
Starting system Recoil starter
Rotation direction(View from flywheel) Clockwise
Lube SAE10W30 (above CC grade)
Low oil pressure alert system
FUZHOU LINGLI POWER Co., Ltd. located in FUZHOU FUJIAN, a famous town of oversea was founded in the early of 2004. Occupying more than 50, 000 square meters, we have more than 270 employees, and more than 30% among them are high technical researchers
We are a professional manufacturer specialized in highly technical power generator as the following series products line:
