Rated frequency(Hz)
50
Rated voltage(V)
400/230
Rated current(A)
11.6
Rated output power(kW)
8.0
Max output power(kW)
9.0
DC output
12V 8.3A
Power factor(cos)
0.8
Phase number
Three phase
Rated rotation speed(rpm)
3000
Structure type
Silent type
Noise level dB(A)7m
68~75
Overall dimension(L*W*H)(mm)
1180*610*830
Dry weight(kg)
272
Engine model
KM290FE
Fuel tank volume(L)
25
Total displacement[L(cu. In)]
0.954(58.22)
Fuel consumption rate[g(ml)/kW. H]
≤200
Starting mode
12V electric statrt
Type
Double cylinder, air-cooled, 4-stroke, direct injection, diesel engine
Fuel
0# (summer), 10# (winter) light diesel oil
Lube
LECD grade 15W40
Compression rated
19: 1
Rated power(kW/rpm)
14.4/3000
Ningbo Yinzhou Xingchen Machine Factory was established in1995, which is located in Ningbo with advantages in geography position. Our factor is professionally engaged in the products of constuction machinery, such as Concrete Vibrator, plate compactor, power trowel, concrete cutters, water pumps. Hand insertion vibrators, rammers, concrete mixer and so on. The products have ready market at lowest price and with good service all over the world.
Lowest Price anywhere we are so sure thet you can't find better concrete vibrator for lower prices. We offer to beat any conpetitor's delivered price within one year from the date of purchase-even if it's an advertised special.
100% Satisfaction Guarantee products featured by harbor freight have passed rigorous inspection by our quality assurance team. Our 100% satisfaction guarantee is our solid commitment to you that if for any reason you are not satisfied with any item, simply return it for a fast, courteous, hassle-free refund.
If the product we offered above is somehow different from what you required actually, please kindly inform us in detail. We will be pleased to re-offer you as your actual requirements.
