Big power generator brushles open type/silent type engine/wei fang engine, deutz engine. Lovol engine. Cummins engine
Stable performance overload protection
Rated power 8kw -500kw speed 1500rpm/1800rpm
Frequency: 50Hz/60Hz rated voltage: 230V/400V
Rated current 14.4A-900A
Motor: Brushless stamfor or leroy summer
Color: Yellow, orange green, white
Output type: AC three phase
|
MODEL |
GF2-350KVA |
|
Powered by Cummins Engine |
|
Prime Power (50HZ/60HZ) |
250KW/313KVA |
|
Standby Power (50HZ/60HZ) |
280kw/350KVA |
|
Power Factor |
0.8 Lagging |
|
Phase Wires |
3-phases 4-Wires |
|
Start Model |
Electric |
|
Protection |
Low oil-pressure, High water temperature,
Over-speed, Over-current |
|
Engine Model |
MTAA11-G3 |
|
Cylinders |
6 |
|
Cylinder Arrangement |
L |
|
Bore x Stroke(mm) |
125X 147 |
|
Compression Ratio |
15.0: 1 |
|
Speed |
1500rpm/1800rpm |
|
Cooling Method |
Water – cooled |
|
Starting Method |
24V DC electrical start |
|
Full Load Diesel Consumption (L/H) |
62 |
|
Engine Displacement (L) |
10.8 |
|
Inspiration (L) |
Turbocharged Intercooled |
|
Lube Volume (L) |
39 |
|
Coolant Volume (L) |
61 |
|
Noise (Db) |
≤ 105 |
|
Governor Type |
Electrical Governing |
|
Alternator Model |
StamfordHCI444ES |
|
Alternator Power |
260KW |
|
Voltage |
220/380 V |
|
Protection |
IP23 |
|
Voltage Regulation |
± 4% |
|
Insulation Class |
H |
|
Voltage Control |
AVR |
|
Net Weigh (KGS) |
3100 (O) 4340(S) |
|
Dimensions (L x W x H) mm |
3150*1120*1535(O) |
|
44510*1500*1900(S) |
|
20FTContainer |
2 units (O) 1units (S) |
|
40GP Container |
6 units (O) 4 units (S) |
As a manufacturer, we specialize in producing big water cooled diesel generator from 8KW to 500kw above. Air cooled gasoline/ diesel engine, small air cooled gasoline/diesel generator set, gasoline/diesel water pump sets, concrete cutter, plate compactor, light tower, high pressure washer and so on products. Have about 10 year experience. Punctual delivery, good quality, competitive price.
If you are interested in any our products, pls let me know. We promise to supply you good quality and service you at first time!
Welcome your any enquiry! Hopefully, we can develop best with your cooperation!
