| Price: | US $ 1500/Piece |
|---|---|
| Trade Terms: | FOB,CIF |
| Min Order: | 5/Piece |
| Pay Type: | L/C,T/T |
Model of Gen-set | Unit | 1GF | 2GF | 3GF | 5GF | 8GF | 10GF | 12GF | 15GF | 20GF | |||
Diesel engine | Rated power | KW | 1 | 2 | 3 | 5 | 8 | 10 | 12 | 15 | 20 | ||
Model |
| 165F | 170F(D) | R175(ND) | S195(ND) | S1100(ND) | ZH1105(ND) | ZH1110(ND) | ZH1125ND | JD330D | |||
12Hours rated | Kw / ps | 2.21/3 | 2.94/4 | 4.4/6 | 8.8/12 | 11/15 | 13.2/18 | 14.7/20 | 19.7/27 | 26.5/36 | |||
Fuel consumption | G/kw.h | 292.3 | 257 | 246.2 | 248.2 | 252.6 | 258.4 | ||||||
Cooling method |
| Air/water-cooled | Evaporation or Radiator | ||||||||||
Starting method |
| Hand cranking or Electric starting | |||||||||||
GEN | Model |
| ST-1 STC-1 | ST-2 STC-2 | ST-3 STC-3 | ST-5 STC-5 | ST-8 STC-8 | ST-10 STC-10 | ST-12 STC-12 | ST-15 STC-15 | ST-20 STC-20 | ||
Rated output | Kw | 1 | 2 | 3 | 5 | 8 | 10 | 12 | 15 | 20 | |||
Rated voltage | V | 230V/115V or 400V/230V | |||||||||||
Rated current | A | 4.34 1.8 | 8.7 3.6 | 13 5.4 | 21.8 9 | 34.8 14.4 | 43.5 18.1 | 52.1 21.7 | 27.1 | 36 | |||
Frequency | HZ | 50/60HZ | |||||||||||
Power factor |
| 1 0.8 | 1 0.8 | 1 0.8 | 1 0.8 | 1 0.8 | 1 0.8 | 1 0.8 | 1 0.8 | 1 0.8 | |||
Phase connection |
| 1-Phase or 3-Phase 4-wire | |||||||||||
Excitation |
| Harmonic excitation or Phase compound or brushless | |||||||||||
| Model |
| BF-S-12 | BF-S-15 | BF-S-20 | ||||||||
Voltage regulation |
| Manual/Automatic | |||||||||||
Net weight | Kg | 90 | 130 | 150 | 320 | 340 | 360 | 360 | 380 | 620 | 680 | ||
Gross weight | Kg | 110 | 150 | 170 | 360 | 380 | 400 | 400 | 420 | 680 | 760 | ||
Packing size L×W×H | cm | 100×52×65
| 164×76.5×102 | 185×73×125 | |||||||||
20FT unit |
| 66 | 18 | 9 | |||||||||
| Prod Model: | GF10 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Engine Brand: | Jd, Changfa, Changchai |
| Type: | Self-Starting Diesel Generator |
| Installation Method: | Portable |
| Stroke: | Four Stroke |
| Cooling Method: | Water Cooling |
| Output Type: | AC Three Phase |
| Conditions Of Use: | Home Use |
