| Price: | US $ 1900-2300/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T |
Features:
1. Powered by heavy duty industrial diesel engine, internation famous brand or China brand diesel engine can be chosen.
2. Radiator 40 degrees max, fans are driven by belt, with safety guard.
3. Brushless, self-excited, IP22/23, insulation H alternator.
4. Absorber to reduce vibration.
5. Dry type air filter, fuel filter, oil filter.
6. Main line circuit breaker.
7. Control system: key start control panel as standard, digital auto start or ATS system is optional.
8. High efficient muffler to reduce noise.
9. Ripple flex exhaust pipe, exhaust siphon and flange etc.
10. Genset type: open type or soundproof/silent type, or trailer type.
11. Maintenance and operation manual for generator, quality certificate, etc.
12. Rigorous testing must be done before delivery, including 50% load, 75% load, 100% load, 110% load and all protection function (over speed stop, high water temperature, low oil pressure, battery charging fail, emergency stop)
| Model of Gen-set | FSH-10D | |
| Rated Power | 10KW | |
| Diesel Engine | Model | 295D |
| 12Hours Ratedoutput | 13.2./18kw/ps | |
| Fuel consumption | 246.2 | |
| Cooling Method | Water cooled | |
| Staring Method | Electric starting | |
| Generator | Model | STC-10KW |
| Rated outpet | 10KW | |
| Rated Voltage | 220V/380V | |
| Rated Current | 43.5 18.1 | |
| Frequency | 50Hz/60Hz | |
| Rower Factor | 1.0 /0.8 | |
| Phase Connection | 3-Phase 4-Wire | |
| Exciation | Harmonic Excitation | |
| Control Panel | Model | BF-S-15 |
| Voltage Regulation | Automateic | |
| Net Weight(kg) | 360kg | |
| Gross Weight(kg) | 400kg | |
| packing SizelxWxH(mm) | 1700×700×1200mm | |
| Prod Model: | FSH-10DS |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Stroke: | Four Stroke |
| Cooling Method: | Water Cooling |
| Output Type: | AC Three Phase |
