Features and benefits:
*A new AVR(Automatic Voltage Regulator)delivers non-fluctuating power.
*Powerful R2V840/R2V870 diesel engine.
*Electric starter ensures easy starting.
*Low oil pressure alert system shuts down the engine automatically.
*Enclosed structure brings quieter operation for the owner.
*Three-phase output meets your different requirements.
| Model | CDE14000E |
| Rated frequency Hz | 50 60 |
| Rated output power kVA | 12.5 13.5 |
| Max. power kVA | 14 15 |
| Rated voltage V | 230 240 |
| Rated current A | 54.4 56.3 |
| Phase No. | Single |
| Power factor (cosφ) | 1 |
| Insulation Grade | F |
| Pole number | 2 |
| Exciting way | Brush, exciting-self voltage-constant (with AVR) |
| Panel type | Intelligent |
| Output socket | Single-phase socket,wiring terminal |
| DC12V output | 12V, 8.3A |
| Dimensions:L×W×H mm | 870×630×700 |
| Net weight Kg | 195 |
| Noise (7m)dB(A) | 82 |
| Structure type | half-closed |
| Engine model | |
| Type | V-twin, two-cylinder, four-stroke, DI |
| Cylinder No. –bore ×stroke mm | 2-88×72 |
| Total displacement ml | 870 |
| Rated power kW/ rated speed r/min | 13/3000 14/3600 |
| Compressed ratio | 20:01 |
| Cooling system | Air-cooled |
| Lubrication system | Pressure & splashing |
| Starting system | Electric |
| Fuel type | 0#(summer)-10#(winter)-35#(cold winter)light diesel |
| Lube oil Brand | SAE10W30 |
| (CD grade above) |
| Lubricating oil capacity (L) | 1.7 |
| Starting motor capacity V-kW | 12V 1.4kW |
| Dynamo capacity V-A | 12V 8.3A |
| Battery capacity V-Ah | 12V 45AH |
| Fuel consumption (g/kW·h) | ≤298 ≤320 |
| Fuel tank capacity (L) | 25 |
| Continuous running time (hr) | 7 6.5 |
Fuzhou Changhua Power Machinery Co., Ltd. Is engaged in research, development, manufacture and selling in various kinds of alternator, engine, generator, water pump. The company with 8, 000 m2 workshop and employs more than 200 staff workers, among which 30 are engineers or technicians. It operates an advanced production line with whole set of inspection and testing equipment and a
Yearly capacity of 200, 000 sets of machines. The company put through EPA, CE, SONCAP and ISO9001, Certificate.
"Reputation is the first, Consumers are supreme"is our persistent working tenet. We have and will serve the consumers with high quality, reasonable price, perfect service and flexible working way.
