Rated frequency(Hz)
50 60
Rated voltage(V)
230 230
Rated current(A)
54.3 54.3
Rated output power(KW)
12.5 12.5
Max output power(KW)
14 14
Rated otation speed(rpm)
3000 3600
Power factor(cos)
1
Phase number
Single phase
Excitation mode
Self-excitation and constant voltage(AVR)
Overall dimension(LxWxH)[mm(in)]
E: 1270x830x940(50.00x32.68x37.01)T: 1660x730x1020(65.35x28.74x40.16)
Dry weigt[kg(ibs. )
E: 360(792), T: 455(1001)
Structure type
E: Open-frame type T: Silent type
Engine model
KM380G
Rated power[kW(Hz)/rpm]
21(28.56)/3000.21(28.56)/3600
Engine type
Three cylinder, in-line, water-cooled, 4-stroke, direct injection, diesel engine
Bore*stroke[mm(in)]
80x90(3.15x3.54)
Compression ratio
181
Total displacement[L(cu. In)]
1.35782.81
Fuel consumption at full load[g(ml)/kW. H]
<245291
Starting system
12V electric starter
Fuel
0#summen-10#(winter)light diesel oil
Cooling system
Forced water-cooled circulation
Lube Capacity[L(gal. )]
38(8.36)
Lube
LECD grade 15W40
Ningbo Yinzhou Xingchen Machine Factory was established in1995, which is located in Ningbo with advantages in geography position. Our factor is professionally engaged in the products of constuction machinery, such as Concrete Vibrator, plate compactor, power trowel, concrete cutters, water pumps. Hand insertion vibrators, rammers, concrete mixer and so on. The products have ready market at lowest price and with good service all over the world.
Lowest Price anywhere we are so sure thet you can't find better concrete vibrator for lower prices. We offer to beat any conpetitor's delivered price within one year from the date of purchase-even if it's an advertised special.
100% Satisfaction Guarantee products featured by harbor freight have passed rigorous inspection by our quality assurance team. Our 100% satisfaction guarantee is our solid commitment to you that if for any reason you are not satisfied with any item, simply return it for a fast, courteous, hassle-free refund.
If the product we offered above is somehow different from what you required actually, please kindly inform us in detail. We will be pleased to re-offer you as your actual requirements.
