We CSCPower, manufacturer specializing in generators,
Are qualified and hoping to supply you with different solutions (quotations+specifications) for generators according to your specific requirements.
Hope more about our generators could be known to you.
About our biogas generator:
Biogas Generator with the features of high efficiency, low energy consumption and environmental protection etc.
CSCPOWER with the model CB natural gas gen-set.
Supply Scope:
1. Brand new gas engine (already mounted on the genset base)
2. Brand new alternator (already mounted on the genset base)
Ratings: 220/380V-adjustable, 3P4W, 50Hz/60Hz, 1500Rpm/1800Rpm, 0.8PF, IP23, H insulation class
3. Anti-vibration mountings (already mounted on the genset base)
4. Test report of generator, Set of drawings and O&M manuals
5. A set of digital automation controllers
6. Standard tools kit
Terms:
Global Warranty: 12 months after installation.
Delivery / Manufuacuring time: 1-4 weeks after receiving down payment
Quality Standards:
Our generating sets meet the following standards: GJB1488, GB/T2820, GB1105, GB/T12786-91, ISO8525, ISO8525-3-5-6. ISO8528
Gensets Factory Testing:
Each our generating sets must get through 1 hour load test for running 0%, 25%, 50%, 75%, 100% and 110% load before dispatch, all protective devices, control functions are simulated and it's system checked, proved and then passed for dispatch. A test certificate can be provided upon request.
Standard Supply Scope |
Exhaust silencer |
Flexible pipes |
Flange |
Base frame |
Main circuit breaker |
Starting battery |
Battery wires |
Battery charger |
Float battery charger |
AVR |
Cooling radiator |
Wires diagram |
Manual books |
Auto control panel |
|
Optional Supply Scope |
Water preheater |
PMG |
ATS |
External daily fuel tank |
Silent canopy |
Lub oil preheater |
Anti-condensation heater |
Synchronization panel |
Automatic fuel pump |
Weatherproof canopy |
Spare parts |
Parallel droop |
ABB breaker |
Oil drain pump |
Mobile Trailer |
Terms: |
Global Warranty: 12 months after installation or 1000hrs running, whichever comes earlier |
Payment term: T/T, 30% deposit, 70% paid before delivery out of factory |
Manufuacuring time: 15-40 days after down payment |
Generator Set Models |
Engine Models |
Generator Models |
Power (kW) |
Fuel Consumption |
Net weight |
Dimension(Open) |
Standby |
Prime |
100%kW.m 3 /h |
kg |
mm |
CB-6B |
465(F10A) |
SCB270-6A |
6 |
5 |
5 |
310 |
1100×750×820 |
CB-8B |
474 |
SCB270-8A |
8 |
7 |
5.5 |
420 |
1400×750×820 |
CB-12B |
491(4Y) |
FD1E-2 |
12 |
10 |
6.5 |
560 |
1620×860×900 |
CB-20B |
4BTA3.9 |
FD1D-2 |
22 |
20 |
15 |
1000 |
1800×750×1150 |
CB-45B |
6BTA5.9 |
FD2B |
45 |
40 |
25 |
1200 |
2100×820×1200 |
CB-120B |
6CTA8.3 |
FD3DS |
120 |
100 |
600 |
1650 |
2350×930×1450 |
CB-160N |
NTA855 |
FD3EM |
160 |
140 |
960 |
3300 |
3300×1300×1850 |
CB-350B |
KTA19 |
FD4LS |
350 |
300 |
2100 |
3850 |
4000×1650×2100 |
CB-550B |
KTA38 |
FD5MP |
550 |
480 |
3300 |
7800 |
4500×1850×2400 |
Fuzhou Century Sea Co., Ltd is a global leading manufacturer of diesel generator sets, alternator and transformer. We are located in Fuzhou, near fuzhou sea port and Fuzhou airport.
We supply diesel generators set, alternator, light tower, trailer genset, marine generators and transformer. The power is range from 10kVA to 3000kVA. We can provide diesel generator with cummins, Duetz, Doosan Daewoo, China egine with stamford, Leory somer alternator, etc. We also manufacture alterantor and medium frequency inverter by ourself. Besides, we have ability to customize gensets according to customers' special demands.
Dedicated to strict quality control and thoughtful customer service, our generator sets have been exported to Europe, South America, Africa, etc. We'd like to join hands with friends from all over the world in different domains on the basis of equality and mutual benefits. With principle of "credit today is future tomorrow", we are looking for agents and talents to join with us and create a great future.
Why to choose CSCPOWER?
1. Army quality, reasonable price
2. Quick delivery time
3. Excellent pre-sale and after sale serice
4. Strong technical support
