Keyo Electric Co., Ltd
Professional manufacturer of slip rings.
Slip rings are used on any kind of rotating machinery.
The KYC18 series slip rings are 18 circuits model type at 2 AMPS per rings.
Main application as following:
Electrical test equipment
Manufacturing and process control equipment
Indexing tables
CCTV pan / tilt camera mounts
Robotics, rotary sensors, urgent illume equipment
Exhibit / display equipment
Aviation, military, instrument, medical equipment.
Mini-type wire-rolling machine
Closed-circuit control
|
Specifications |
|
Operating Speed |
0-300 rpm |
|
Number of Circuits |
18 |
|
Voltage |
240 VAC/DC |
|
Current Rating |
2 amps/per circuit |
|
Temperature Range |
-40ºC to +80ºC |
|
Contact Material |
Gold to Gold |
|
Wire Size |
AWG26 silver plated copperUL R , Teflon R |
|
Wire Lengths |
200 mm minimum |
|
Dielectric Strength |
500 VAC @50Hz, between eachcircuit and all other circuits |
|
Insulation Resistance |
1000 megohms @ 500 VDC |
|
Noise |
70mΩ max.. d @ 6 VDC50 mA ,(operating at 5 rpm) |
|
Capsule Length =L |
|
Number of Circuits |
L (mm) |
Part No |
|
18 |
35.03 |
KYC-18A |
|
The operating life of the unit depends upon temperature, rotation speed and environment. |
