Keyo Electric Co., Ltd
Professional manufacturer of slip rings.
Slip rings are used on any kind of rotating machinery.
The KYC12 series slip rings are 12 circuits model type at 2 AMPS per rings.
Main application as following:
1 Electrical test equipment
2 Manufacturing and process control equipment
3 Indexing tables
4 CCTV pan / tilt camera mounts
5 Robotics, rotary sensors, urgent illume equipment
6 Exhibit / display equipment
7 Aviation, military, instrument, medical equipment.
8 Mini-type wire-rolling machine
9 Closed-circuit control
specifications |
Operating Speed |
0-300 rpm |
Number of Circuits |
12 rings |
Voltage(max) |
240 VAC/DC |
Current(max) |
2 amps /per circuit |
Temperature Range |
-40ºCto +80ºC |
Contact Material |
Gold to Gold |
Wires Size |
AWG30 silver plated copper ULTeflon ® |
Wires Lengths |
250 mm minimum |
Dielectric Strength |
500 VAC @50Hz, between each circuit and all other circuits |
Insulation Resistance |
1000 megohms @ 500 VDC |
Electric Noise |
≤8mΩ |
Keyo Electirc Co., Ltd., is one of the leading manufacturers of high voltage and low voltage switchgear and accessories in China.
Innovation is our experience. From the beginning of foundation, we emphasize in development and production of brand new, technology intensified, miniatureized, intellgent, scaled products. We have been cooperating with member factories to manufacture other electrical and electronic goods and accessories, aiming to develop new products with strong guarantee of scientific contents.
The company has passed ISO9001, 2000 Quality System Approval, all the products have got production licence of National Mechanichal Industry D-epartment and CCC Certification of National Compulsory Approval Center.
Keyo Electirc Co., Ltd., always pursues the promise of Credit First, Service Best, facing the market home and abroad, wish to build and strengthen the close co-operation with the customers, marching with you hand in hand and creat a bright future.
