Air-Cooled Single Cylinder Diesel Generator Single Phase (DG7500SE)

Air-Cooled Single Cylinder Diesel Generator Single Phase (DG7500SE)
Price: Negotiable/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 5/Piece
Pay Type: L/C,T/T,Western Union
Air-cooled Diesel Generator Set(DG7500SE)

With 12HP HR188FA diesel engine, ensure the rated output reach 5.5KW and max. Output can reach 6KW; Silent model can control the noise under 72dbs, applied by several families!

1. We are manufactory, could give best suggestions to customers.

2. Professional general engineers and technical team.

3. Have spare parts for customers' exchange.

4. Warranty: Running 500 hours or one year.

5.100% copper good brand alternator, every spare parts suppliers are choosed extremely stricted, to control the quality well.

6. From engine to whole genset, we test every link of every product, have test machinery and test center.

7. Many spare parts are produced by ourselves, could save cost for customers greatly.

8. We welcome every customer visiting our factory and test our products.

We are professional generator manufacture, I think we must have one type even more can match what you need!

Just send us your inquiry, we will high appreciate it!
Frequency(HZ) 50 60
Max.output(kw) 5.5 6
Rated output(kw) 5 5.5
Rated.AC voltage(V) 120,220,230,120/240
Power factor(cosΦ) COSΦ=1
DC output (V) 12V/8.3A
Phase Single phase
Alternator type self-excited,2-pole,single-phase alternator
Starting system Electric
Operating noise level(at 7m) 68~72
Fuel tank capacity(L) 16
Continues work(hr)      7.3                   7
Engine type Single-cylinder,vertical,4-stroke air-cooled diesel engine
Bore×stroke(mm) 88×72
Fuel 0# or -10# light diesel oil
Lubrication oil volume(l) 1.65
Combustion system Direct lnjection
AC Output Socket 2
AC circuit breaker yes
Oil warning light yes
Oil alert yes
OPTIONAL FEATURES DC circuit breaker optional
Calculagraph optional
Big Wheel optional
Three phase voltage optional
Current meter optional
ATS optional
Remote control optional
Welding optional
DIMENSIONS Dimension (L×W×H)(mm) 960*555*780
Net weight(kgs) 175 176
20FT 72
Prod Model: DG7500SE
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Engine: 12 HP Diesel Engine Hr188fa
Generator Power: 5kw
Engine Rpm: 3000
Noise: 68-72DBS
Cooling Method: Air Cooled
Stroke: Four Stroke
Installation Method: Portable
Type: Basic Diesel Generator
