New Model
Z-1000
Name
Dolphin
Rated power
1000W
Rated DC voltage
24/48V(Optional)
Rated current
42/21A
Rated speed
650r/m
Max power
1200W
Number of blade
3 PCS (package Individually)
Starting wind speed
3m/s
Cut-in wind speed
3.5m/s
Cut-out wind speed
15m/s
Security wind speed
45m/s
Rated wind speed
12m/s
Engine
Three-phase permanent magnel generator
Rotor diameter
2200mm
Blade material
FRP (fiber glass- reinforced plastics)
Output line anti-winding device
Over all three-phase commutator
Over-speed wind protection
Tip stall protection + tumed protection + electomagnetic brake
Life span
15 years
Equipment surface protection
Aluminum oxide + plastic coating
Working temperature
-40° C-70° C
N. W.
25kg
Packing material
Carton case and foam material
Packing dimension
850*550*460mm
G. W.
27kg
Shenzhen Wind Power Co., Ltd is a company specialized on medium & small wind turbine generator group and relevant parts development, manufacturing and selling.
We pay high attention on science development. We own professional persons and research equipments on aerodynamics analyse, mechanical design, generator design&manufacturing, also electrical regulate. Based on wind turbine whole set basic theory, every model go from science aerodynamics calculate, intensity analyse, electromagnetic calculate, efficiency study, jarring analyse and matching analyse, all have detailed design, test and produce plan. The wind turbine passed wind tunnel test. Whole system function and various working conditions all have detailed test reports.
Professionally organized and managed, we spare no effort in ensuring the supply of high quality various wind turbine and guarantee 100% service satisfaction for national & overseas consumers. Accordingly, all of our products conform to CE and ISO9001 quality standards.
We engaged in wind turbine generator development and application, we launched 300W, 500W, 1kw small wind turbine in 2000. When time goes by, our technology and products gradually matured, we launched 2kw, 3kw, 5kw, 10kw, 20kw wind generator.
Therefore, if you or your company are interested in any of our products, please don't hesitate to contact us for more details. We look forward to supplying you with our high quality products in the near future.
