FD6.0- 5KW
type of wind generator:Permanent magnet
blade diameter: 6.0 m
blade material:fiber glass reinforced
rated wind speed : 10m/s
rated output power: 5000W
max power: 7000W
output Voltage : 220V
startup wind speed : 3m/s
work wind speed: 3-25m/s
security wind speed 40m/s
tower type:159mm159mm pull wire tubular tower
tower high: 9m
Top section weight: 250kg
output controller system (controller &wine wave inverter)
service life : 20-25 years
can supply power for:air conditioner,small gas station,tollgate,refrigerator,washing machine,waterpump,electric cooker,colorTV,lighting,electric fan and charging.
| Power | 200W | 300W | 600W | 1KW | 2KW | 3KW | 5KW |
| Diameter of wind wheel | 2.2 | 2.6 | 2.8 | 3.2 | 4.0 | 5.0 | 6.0 |
| Rated speed (rpm) | 400 | 400 | 400 | 400 | 400 | 240 | 220 |
| Rated wind speed | 8 | 8 | 8 | 8 | 9 | 10 | 10 |
| Rated power | 200w | 300W | 600W | 1KW | 2KW | 3KW | 5KW |
| Maximum power | 350w | 450w | 750W | 1.5Kw | 3Kw | 4.5KW | 7KW |
| Output voltage | 24v | 24v | 24v | 48v | 96v | 220v | 220V |
| Starting wind speed | 3 | 3 | 3 | 3 | 3 | 3 | 3 |
| Working wind speed | 3-25 | 3-25 | 3-25 | 3-25 | 3-25 | 3-25 | 3-25 |
| Guy master tower height m | 6 | 6 | 6 | 6 | 6 | 8 | 9 |
| Tower size (diameter*thickness)mm | 60*3 | 60*3 | 75*4 | 75*4 | 89*4 | 133*5 | 159*5 |
| Controller parameter | 24V 40A | 24V 40A | 24V 40A | 48V 60A | 96V 60A | 220v 60A | 220v 60A |
| Inverter Parameter | DC24V user’s local voltage requecy | DC24V user’s local voltage frequecy | DC24V user’s local voltage frequecy | DC48Vuser’s local voltage freque | DC96V user’s local voltage freque | DC192Vuser’s local voltage freque | DC220user’s local voltage freque |
| Suggested capacity of storage battery | 12V100AH 2 pcs | 12V100AH 2 pcs | 12V150AH 2 pcs | 12V150AH 4 pcs | 12V100AH 8 pcs | 12V100AH 16 pcs | 12V100AH 18 pcs |
We specialize in this field for several years, with the strength of wind turbines, with good quality and pretty competitive price. SHANDONG JIALI NEW ENERGY Co., Ltd founded in 1994, specialized in manufacturing wind turbines, the main products are 200W, 300W, 600W, 1KW, 2KW, 3KW, 5KW, 10KW, 20KW, 30KW, 50KW and 100KW wind turbines and small solar panels, wind solar hybrid systems. Products are exported to the United States, Germany, Britain, France, Pakistan, Indonesia, Mongolia, has a customers high praise.
