About Us
Company founded in 1994, specialized in manufacturing wind turbines, the main products are 200W, 300W, 600W, 1KW, 2KW, 3KW, 5KW, 10KW, 20KW, 30KW, 50KW wind turbines and small solar panels, products are exported to the United States, Germany, Britain, France, Pakistan, Indonesia, Mongolia, has a customers high praise.
Product quality are reliable, the company developing on "technology to survive, quality to develop " and has passed CE, ISO9001 international quality certifications, from the technical design, product manufacturing, product inspection, etc. Have been used to maintain a complete management system.
1.35% more electricity generated
2. Pitch controlled
3. Aerodynamicbrake
4.3 year quality warranty
5. Low start-up wind speed...
2)G1)Generator: Alluminum Alloy material, lighter and beautiful
Enerator type: Permanent-magnets- 3 phase A. C.
2) CE &ISO9001 approved
3) with slip ring and carbon brush to avoid twist
4) guy wired tower or free stand tower according the clients' requirement.
5) has exported to at least 80countries and areas.
Playwood case
Way speed limits: Yaw&Magnetic resistance
| Power | 50000W |
| Type of generator | Permanent-magnet -3phase A.C. |
| Blade diameter | 18.0m |
| Blade Material: | FRP (Fiber glass reinforced*3 ) |
| rated rotor speed | 60r/min |
| rated speed | 10m /s |
| rated Power | 50000W |
| max Power | 55000w |
| Range of voltage output | DC420V-DC620V(or)AC300V-AC440V) |
| Rated current output | 30A |
| Protection degree | IP11 |
| Rated voltage output | DC540V (or AC380V) |
| start up wind speed | 3.5(m/s) |
| work speed | 3.5-20(m/s) |
| security wind speed | 40(m/s) |
| Rate-limiting mode | Hydraulic brakes, PLC control |
| Dogvane | Measurement of wind turbine angle agaist wind |
| Anemoscope | Testing real-time wind speed and then transfer the signal to controller |
| height of Free sdand tower | 30m (hot galvanized and plastic spraying) |
| top quality except tower | 2050kg |
| Total weight(kg)(with30m) Free sdand tower | 11050 |
| output controller system |
Controller , Inverter |
| can supply power for | Small Village , air-condition, refrigerator, washing machine , water pump ,electric pan, color TV, lighter, fanner, charger |
We specialize in this field for several years, with the strength of wind turbines, with good quality and pretty competitive price. SHANDONG JIALI NEW ENERGY Co., Ltd founded in 1994, specialized in manufacturing wind turbines, the main products are 200W, 300W, 600W, 1KW, 2KW, 3KW, 5KW, 10KW, 20KW, 30KW, 50KW and 100KW wind turbines and small solar panels, wind solar hybrid systems. Products are exported to the United States, Germany, Britain, France, Pakistan, Indonesia, Mongolia, has a customers high praise.
