This permanent magnet generator use for wind turbine, with brake system, can automatic stop generator turn around when speed over 1.2 times rated speed
| Power | FF-1KW | FF-2KW | FF-10KW | FF-20KW |
| Rated Voltage | 56v(dc) | 115v(dc) | 230v(dc) | 400v(ac) |
| Rated Current | 26.8A | 17.4A | 43.5A | 28.87A |
| Rated Speed | 360rpm | 300rpm | 200rpm | 140rpm |
| Start torque | <1.2N.M | <2.0N.M | <6.5N.M | <20N.M |
| Weight(KG) | 20KG | 60KG | 230KG | 520KG |
Xinda Green Energy Co., Limited is specialized in handling the business of vertical and horizontal wind turbine generator, various kind of permanent magnet generator(0.05-3000kw), speed from 20rpm-20000rpm, both vertical and horizontal, small hydro turbine system(low head and higher head), wind solar hybrid system, high efficiency high seepd permanent magnet motor, street lamp and so on
Our partner manufacturers are committed to continuously improving our operations and meeting the needs of our customers through innovation and new product development. We work closely with them to optimize the performance and cost-effectiveness of their processes.
