Prodcut Name: 50KW Wind Turbine
System Application
1. Independent power station: Be suitable for area without electric power because power grid cannot cover. System stores power by storage battery, and the user could get the power from battery through inverter when need to power.
2. On-grid system: The power from wind generator connects with power grid. The user generates power by them for saving the charges, or sells power to local electric company under the allowing policy.
Features:
1. FD series products adopt aluminium alloy housing with good heat dispersion and easy to maintain.
2. Main controlling components use international famous brand, and the product quality is reliable.
3. Adopt touch human-computer interface and GPRS remote controlling, and supply convenience for inspecting running situation of wind turbine.
4. Ultrasonic wind measuring device can survey more accurately data about wind speed and direction.
5. Tripling protection system ensures the running safety of equipment.
Technical parameters:
| Model No. | FD-50KW |
| Rated power(W) | 50000 |
| Rated voltage(V) | 220 |
| Rated current(A) | 227 |
| Start-up wind speed(M/S) | 2.5 |
| Rated wind speed(M/S) | 12 |
| Cut-out wind speed(M/S) | 20 |
| Security wind speed(M/S) | 60 |
| Rated rotational speed(RPM) | 60 |
| Rotor diameter(M) | 16.2 |
| Blade number(PCS) | 3 |
| Blade material | GFRP |
| Generator mode | Permanent magnet synchronous |
| Protecting mode | Yaw, brake and unload |
| Controlling mode | PLC intellectual control |
Package:
Plywood case and naked
Delivery time:
Within 30 days after signing the contract or proforma invoice and receiving the downpayment.
Our company set up more than ten years. We have abundant experience to produce and export wind generator. The products have exported to a lot of countries in the world. They get our clients' confirmation according to their reasonable prices and good quality.
We are interested in establishing business relationship with you.
