500W/600W Home Use Wind Turbine
| Price: |
US $ 300-860/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
5/Piece |
| Pay Type: |
L/C,T/T,Western Union |
500W/600W Wind Turbine1. Warranty: 5 years.
2. 20 years life span.
3. CE, &ISO&16patents
4. Mechanism yawingFeatures of FD-M series: 500W, 600W wind turbine1. Magnetic saturation generator design, 20years designed life. (Patent No.: ZL 2007 2 0010261.7)
2. 2-2.5m/s start-up wind speed under low torque start-up technique. (Patent No.: 201020259728.3)
3. Mechanical automatic yawing.
4. Match controller with constant voltage charging, electronic and manual brake, and numeral panel display. (Patent No.: 200910213782.6)
5. 500W, 600W blades are casted into molding at one time with balance up to 99%.
6. Bearings import from Japan (NSK), long service time (5 years maintenance-free).
7. Magnetic saturation design, the generator coil couldn't burn down because of the increasing power, when generator runs at a super wind speed and saturates automatically.
8. Low cut in wind speed (3m/s) to guarantee the maximum generation at low wind speed. Pictures for reference:
Generator workshop
Certificate & patents:
|
Model |
FD2.7-500 |
FD2.6-600 |
|
Rated power(W) |
500 |
600 |
|
Rated voltage(V) |
24 |
24 |
|
Rotor diameter(m) |
2.6 |
2.6 |
|
Start-up wind speed(m/s) |
2 |
2 |
|
Cut-in wind speed(m/s) |
3 |
3 |
|
Rated wind speed(m/s) |
8 |
8 |
|
Safety wind speed(m/s) |
35 |
35 |
|
Yawing type |
Mechanism |
Mechanism |
|
Rated rotating rate(r/m) |
380 |
380 |
|
Generator material |
Aluminum alloy |
Aluminum alloy |
|
Blade material |
Fiber glass |
Fiber glass |
|
Blade quantity |
3 |
3 |
|
Guy cable tower |
Tower height(m) |
6 |
6 |
|
Tower thickness(mm) |
3.5 |
3.5 |
|
Tower diameter(mm) |
89 |
89 |
|
Matched controller specification: |
|
Model |
FDC-500 |
FDC-600 |
|
Rated Power |
500W |
600W |
|
Rated DC Voltage |
24V |
24V |
|
Over-discharge protection voltage |
21V |
21V |
|
Over-discharge recovery voltage |
23.5V |
23.5V |
|
Over-charged protection voltage |
30V |
30V |
|
Over-charged recovery voltage |
29V |
29V |
|
Regulative voltage |
28V |
28V |
|
Max. charge current |
23A |
23A |
|
Unload current |
≤100mA |
|
Cooling type |
Auto cooling & fan |
|
Protection |
Over-charge, over-discharge, unloading, manual braking, etc. |
| Prod Model: |
FD2.7-500; FD2.6-600 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Name: |
500W/600W Home Use Wind Turbine |
| Generator Type: |
Three Phase Permanent Magnetic Generator |
| Yawing Type: |
Mechanism Yawing |
| Blades Material: |
Fiber Glass |
| Warranty: |
5 Years |
| Start-up Wind Speed: |
2m/S |
| Certificate: |
CE&ISO9001 |
| Package: |
Plywood |
| Protection: |
Electronic and Manual Brake |
| Cut In Wind Speed: |
3m/S |
| Rotating Shaft: |
Horizontal |
| Number Of Blade: |
Three Blade |
| Stress Way Of Blade: |
Resistance |
Foshan Ouyad Electronic Co, Ltd was founded in 1998, covering an area of more than 20, 000 square meters. We have our own independent wind turbine manufacturing plant and R&D department of wind turbine generator control system, solar panel, grid tie inverter, off grid inverter, battery, etc. The headquarters are located in Guidan Road, Nanhai district, Foshan city with convenient transportation. At an early time, our company was famous for producing a variety of inverters at home and abroad. In 2005, we began to R&D and produce new energy products, and set up R&D center in Shenyang, R&D generator and brushless DC generator, and obtain great success, with 15 terms of new patents have been reported. Depending on powerful technical strength and many years manufacturing experience, Ouyad has rapidly developed into a new energy production manufacturer with a core of wind turbine system research. Our company established marketing sales and service center in Washington State in 2010. Ouyad was CE certified and has passed ISO9001 international quality management system certification, and UL certified is being tested. Our company has possessing a large of professional, and we have advanced production facility and professional inspection(testing)equipment.
The main products include the main classes:
1. Wind turbine 500W to 200KW (generator+ blades+ tower), etc.
2. Controller: (PWM&MPPT, optional)
3. Inverter: Solar inverter, off grid inverter, on grid inverter, home UPS, inverter.
4. Battery: Deep cycle(solar) battery, gel battery, sealed lead acid battery.
5. Solar panel, complete specifications from 5W to 300W (include both mono and poly crystalline)
