Prod Model: |
CDCY40KVA |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Generator: |
40kVA Silent Generator |
Generator Engine: |
Y4105g |
Alternator Model: |
Stamford |
Generator Controller Brand: |
Smartgen |
Genterator Cylinders: |
4 |
Generator Canopy: |
Silent |
Type: |
Self-Starting Diesel Generator |
Installation Method: |
Fixed |
Stroke: |
Four Stroke |
Cooling Method: |
Water Cooling |
Output Type: |
AC Three Phase |
Product Description
Professional Generator OEM Factory in Guangzhou
Stock available
Generator Set Model | CDY-40kva |
Generator Set Power | 32kw/40kva |
Generator Powered by YANGDONG Engine |
Diesel Engine Model | Y4105G |
Engine Characters | Water-cooled, in line, 4-cycle, direct injection, 1500rpm |
Bore x Stroke (mm) | 105x100 |
Rated Output | 38kw/47.5kva |
Fuel Consumption (g/kw.hr) | <262 |
Lube Consumption (g/kw.hr) | <2.72 |
Compression Ratio | 18 |
Starting | Electric (12V) |
ALTERNATOR MODEL | LEADTECH 184J |
Rated Power | 32kw/40kva brushless with AVR |
Voltage (V) | 220/380V 230/400V 240/415V 127/220V |
Current (A) | 60A |
Frequency (Hz) | 50HZ |
Power Factor (cos¢) | 0.8 |
Brush/Brushless | Brushless |
Dimensions (LxWxH) mm | S: 2200x950x1250 |
Gross Weight (KGS) | 600 |
20FT | 12 PCS |
Controller | Smartgen 6110 or Deepsea 7320 |
Standard | Muffler |
| Battery 80A*1 |
40kva Silent generator |
Generator Specifications | Generator Model | CDC32KW/40KVA |
Generator Prime Power | 32KW/40KVA |
Generator Standby Power | 35KW/44KVA |
Generator Alternator | Stamford; Marathon; |
Canopy for Choice | Silent, super silent |
Controller | Smartgen |
Dimensions (L*W*H) | 2200x950x1250 2600*1100*1650(Super Silent) |
20FT/40HQFT Container | 12PCS |
Generator Warranty | 1800 hours or 1 year subject to the earlier one. |
Generator MOQ | 1PCS |
Certificate | SGS ;Cummins Authorized Factory; TUV; Soncap |
Payment | T/T or Cash |
Please give detail needs in your inquiry, so that we can make power solutions for you. |
Guangzhou Jiuan Mechanical & Electrical Co., Ltd. is a professional generator manufacturer and exporter with generator capacity from 2kVA to 2000kVA. Generator can be powered by Cummins, Perkins, ISUZU, KUBOTA and Chinese engine. Welcome to chose our products and don' T hesitate to contact us.
Our Diesel Generator Set Production Range is as follows:
* Engine (motor) for Choice
1. Cummins (USA ) 20kVA - 1500kVA
2. Perkins (UK) 8kVA-1000kVA
3. Deutz (Germany) 20kVA - 150kVA
4. ISUZU (Japanese) 20kVA - 40kVA
5. Kubota (Japanese) 7kVA-50kVA
6. Lovol (China) 20kVA - 150kVA
7. Yangdong (China) 8kVA - 40kVA
8. Weichai (China) 8kVA - 150kVA
9. Shanghai Engine
10. Yuchai Engine
* Canopy for Choice
1. Silent type (75- 80 dB(A) at 7 meters)
2. Super Silent type (65-70 dB(A) at 7 meters )
3. Open type
4. Trailer type (mobile)
5. Container Type
6. Parallel System
* Alternator for Choice
1. Stamford
2. Leroy Somer
3. Marathon
* Controller
1. Smartgen
2. Deepsea (UK Brand and imported)
