1. Factory Directly! Professional generator OEM factory Guangzhou
2. Super silent 60dB(A) at 7 meters
3. Certificate: SGS, Soncap approval
4. Super silent brand new Cummins engine/Stamford alternator/auto start
Generator stock 30kVA 15kVA 60kVA 100kVA 150kVA 200kVA Shipping at once.
Features of Gen. Set powered by Cummins Engine
1.12 months world-wide warranty service
2. Short delivery time, as we always have Cummins engine in stock
3. Spare parts are easy to get from worldwide market with much cheaper price
4. Perfect after-sales service network
5. Both 50Hz @1500rpm and 60Hz@1800rpm are available
6. Rigorous test including 50% load, 100% load and 110% load
7. Stronger power with reasonable price
8. International brand feel free to use
Alternator Features:
1. World famous brand AC alternator: Stamford, Leroy somer, Marathon, Faraday, copy Stamford
2. Brush less with AVR
3. Brush less 4 poles, rotation magnet
4. AVR Voltage regulation less than ± 1%, AVR self-regulated
5. Protection class IP23
6. Insulation system is class "H"
Control System Features:
Standard Smartgen 6120 or Deepsea DSE6020
Language Display: English; Spanish; Russian; Chinese
Data Display: Power, Voltage, Current, Frequecny, Speed, Oil pressure, Water Temperature, Fuel Level
Protection (auto alarm system): High voltage; Low voltage; High Speed; Low Speed; Over Current; Lose Phase; Low oil pressure; High water temperature
Functions: Auto start; Auto stop; ATS(auto transfer system); AMF(auto mains failure system)
JIUAN Genset testing items:
1. Loading testing: All qualified generator sets are subjected to a comprehensive performance test which includes 0% load, 25% load, 50% load, 100% load and 110% load to check verify that all control systems, alarm and shut-down protection.
2. Parts fault testing.
3. Fuel tank pressure testing.
4. Bolt tightening torque testing.
5. Voltage bearing and insulation testing
6. Noise level testing
3. After-sales Service
1 year or 1800 running hours subject to the earlier one.
24 hours after-sales contact number: 0086 18520604611
4. Terms of Payment
1. T/T
2. Western Union
3. Cash
Company Show
1. Introduction of Company
Business Type: Manufacturer
Location: Guangzhou, China (Mainland)
Year Established: 2008
Registration No.: 440111000040106
Main Products:
Professional diesel generator OEM factory.
3. Production Line of Product
Our Diesel Generator Set Production Range is as follows:
* Engine (motor) for Choice
1. Cummins (USA ) 20kVA - 2000kVA
2. Deutz (Germany) 20kVA - 150kVA
3. (UK) 8kVA - 2000kVA
4. ISUZU (Japanese) 20kVA - 40kVA
5. Lovol (China) 20kVA - 150kVA
6. Yangdong (China) 8kVA - 50kVA
7. Weichai (China) 8kVA - 150kVA
8. Shanghai Engine
9. Yuchai Engine
10. KUBOTA Engine 10kVA - 50kVA
* Canopy for Choice
1. Silent type (75- 80 dB(A) at 7 meters)
2. Super Silent type (65-70 dB(A) at 7 meters )
3. Open type
4. Trailer type (mobile)
5. Container Type
6. Parallel System
* Alternator for Choice (brushless with AVR)
1. Stamford Newage
2. Leroy Somer
3. Marathon
4. Leateck
4. Where Our Generator Used for?
Home, Factory, Hotel, Restaurant, Building site, Super market, Hospital etc
5. Why Choose Us?
Good Reasons Why You Choose JIUAN Generator:
1. Professional Generator OEM factory in Guangzhou.
2.14 years experience in generator and exporting.
3. High quality products at affordable prices.
4. Products lines verified by professional inspectors.
5. Place orders safety.
6. All engines and alternators are brand new and original - Credible.
7. Controller Deepsea or Smartgen -BIG Brand.
8. Air Breaker ABB CHNT Schneider ASK - Safety.
9.1% parts free are available for your order.
6. Welcome to contact us
Www.Jiuan-power.Com
| MODEL | CD-C24KW/30KVA |
| Powered by Cummins Engine |
| Prime Power (50HZ) | 24KW/30KVA |
| Standby Power (50HZ) | 25kw/31KVA |
| Power Factor | 0.8 (Lagging) |
| Phase Wires | 3-phases 4-Wires |
| Start Model | Electric |
| Protection | Low oil-pressure, High water temperature,
Over-speed, Over-current |
| Engine Model | DCEC Cummins 4B3.9-G1 4 Cycle |
| Cylinders | 4 |
| Cylinder Arrangement | L |
| Bore x Stroke(mm) | 102X 120 |
| Compression Ratio | 16.5:1 |
| Speed | 1500rpm |
| Cooling Method | Water – cooled |
| Starting Method | 24V DC electrical start |
| Full Load Diesel Consumption (L/H) | 6 |
| Engine Displacement (L) | 3.9 |
| Inspiration (L) | Natural |
| Lube Volume (L) | 9.5 |
| Coolant Volume (L) | 20 |
| Noise (Db) | ≤ 80 |
| Alternator Model | Newage Stamford PI144G or Leadtech LTG184G |
| Alternator Power | 24KW/30KVA Brushles with AVR |
| Voltage | 380/220V,400/230V,415/240V,220/127V |
| Protection | IP23 |
| Voltage Regulation | ±4% |
| Insulation Class | H |
| Voltage Control | AVR |
| Net Weigh (KGS) | 950 |
| Dimensions (L x W x H) mm | 2300*1000*1400(S)
2600*1100*1650(Super Silent) |
| Controller | Smartgen 6110 or Deepsea 7320 |
| Standard | Muffler * 2PCS |
| Battery 80A * 2 PCS |
| Optional | ATS (auto transfer switch) |
| AMF(auto mains failure) |
| Trailer |
Guangzhou Jiuan Mechanical & Electrical Co., Ltd. is a professional generator manufacturer and exporter with generator capacity from 2kVA to 2000kVA. Generator can be powered by Cummins, Perkins, ISUZU, KUBOTA and Chinese engine. Welcome to chose our products and don' T hesitate to contact us.
Our Diesel Generator Set Production Range is as follows:
* Engine (motor) for Choice
1. Cummins (USA ) 20kVA - 1500kVA
2. Perkins (UK) 8kVA-1000kVA
3. Deutz (Germany) 20kVA - 150kVA
4. ISUZU (Japanese) 20kVA - 40kVA
5. Kubota (Japanese) 7kVA-50kVA
6. Lovol (China) 20kVA - 150kVA
7. Yangdong (China) 8kVA - 40kVA
8. Weichai (China) 8kVA - 150kVA
9. Shanghai Engine
10. Yuchai Engine
* Canopy for Choice
1. Silent type (75- 80 dB(A) at 7 meters)
2. Super Silent type (65-70 dB(A) at 7 meters )
3. Open type
4. Trailer type (mobile)
5. Container Type
6. Parallel System
* Alternator for Choice
1. Stamford
2. Leroy Somer
3. Marathon
* Controller
1. Smartgen
2. Deepsea (UK Brand and imported)
