2014 cheap price of the 5000W solar panel made in China
MODULE M200-B-54
Encapsulation Glass/ EVA/ Cells/ EVA/ TPT
Size and Number of cells 156mmx156mm 54/6x9PCS
Maximum Power (Pmax) W 190 195 200 205 210 215 220 225 230
Power Tolerance ± 0.3%
Open Circuit Voltage (Voc) V 33.2 33.2 33.6 33.6 33.6 33.7 33.7 34.2 34.2
Short Circuit Current (Isc) A 7.84 8.02 8.10 8.24 8.33 8.34 8.35 8.41 8.05
Maximum Power Voltage(Vmp) V 26.2 26.2 26.2 26.3 26.4 27.0 27.5 28.0 28.5
Maximum Power Current (Imp) A 7.25 7.46 7.63 7.79 7.95 7.96 7.99 8.03 8.06
Max. Syst. Oper. Voltage V 1000V
Diodes 3 by-pass
Dimension mm 1482x990x50
Weight kg 18.5
Operate Temp. Scope -40 / +85
Relative humidity 0 to 100%
Resistances 227g steel ball fall down from 1m height and 60m/s wind
Warranty Pm is not less than 90% in 10 years and 80% in 25 years
