300W monocrystalline solar module
Monocrystalline solar module
Monocrystalline silicon solar PV module
Monocrystalline modules
Photovoltaic solar modules, Monocrystalline solar panels
We can manufacture solar panel(mono-crystalline and poly-crystalline) from 0.5W to 300W.
The annual outputting for solar panels is about 80MW. Our products with high quality, and is produced under the international quality control system:
TUV, IEC61215, IEC61730, CE and ISO9000: 2001.
PARAMETER:
Maximum power (Pmax): 300W
Voltage at Pmax (Vmp): 34.94V
Current at Pmax (Imp): 8.61A
Warranted minimum Pmax: 291W
Short-circuit current (Isc): 9.08A
Open-circuit voltage (Voc): 45.09V
Temperature coefficient of Isc: (0.065± 0.015)%/ ° C
Temperature coefficient of Voc: -(160± 20)mV/° C
Certificate: TUV, IEC61215, IEC61730, CE and ISO9001: 2000.
Solar panel relevant index:
1) Long lifetime: More than 25years, less power decrease.
2) Good performance of preventing from atrocious weather such as wind and hails.
3) Resisting moisture and etching effectively, not effect by geology.
4) Warranty: 5 year product warranty, and Pmax is no less than 90% in 10 years and 80% in 20 years.
5) Tolerance: +/-5%, solar cell's efficiency can get to above 16%.
6) Certificate: TUV, IEC61215, IEC61730, CE and ISO9001: 2000.
7) System voltage: 12V/24V/36V/48V
*** 5 watt to 300 watt is available, welcome inquiry for details ***
